Titan 1140i Airless Sprayer Parts & Repair Diagrams
Shop genuine replacement parts for your Titan 1140i Airless Sprayer at AllTitanParts. Dedicated assembly pages help you locate components, compare diagram references, and build an accurate parts list for maintenance or repair.
Begin with the assembly fitted to your machine, then match the diagram callout to the listed part number. Confirming your sprayer’s model, serial number, and cart configuration before ordering helps you select the correct replacement.
Find Your 1140i Parts in Four Steps
1. Identify the Sprayer
Record the model and serial number from the equipment label and note its cart configuration.
2. Choose an Assembly
Open the assembly page containing the component you need to inspect or replace.
3. Match the Reference
Locate the numbered diagram callout and use its associated manufacturer part number.
4. Confirm the Contents
Review compatibility, replacement-number notes, supplied components, and the quantity required.
Browse Titan 1140i Assembly Parts
Choose the relevant section below to compare parts with your installed equipment.
Main Assembly Parts
Find listed components such as the fluid section, siphon tube, inlet screen, bypass tube, fittings, and mounting hardware.
Drive Assembly Parts
Browse the gear box, second-stage gear, slide assembly, bushings, pressure control components, and associated hardware.
Fluid Section Parts — 800-300
Identify pump service components, including the upper seal retainer, upper packing, lower packing assembly, wear ring, and piston rod.
High Rider Cart Parts — 800-600
Use this cart section when matching replacement components for a High Rider configuration.
Filter Assembly Parts — 800-900
Locate the filter assembly diagram and check the listed parts against your installed filter.
Low Rider Siphon Set Parts
Compare the Low Rider siphon diagram with the intake arrangement fitted to your machine.
Low Rider Cart Parts — 800-590
Select this section to identify cart components for the Low Rider configuration.
PRIME/SPRAY Valve Parts — 800-915
Find listed valve service items, including the housing, seat, stem, handle, spring, seals, and cam base.
Sprayer Accessories
Explore listed accessories and confirm each item’s connections and specifications before ordering.
Check Fitment Before You Buy
| Selection Detail | What to Confirm |
|---|---|
| Sprayer identification | Use the model, serial number, and applicable diagram revision to identify the correct equipment configuration. |
| Cart configuration | Choose the cart and intake diagram that matches the equipment in front of you. |
| Pump components | Compare the installed fluid section and component references before selecting individual parts or an assembly. |
| Drive and control components | Verify the exact part number and any applicable electrical specifications or replacement notes. |
| Package contents | Read the listing to determine which components are supplied and which items must be ordered separately. |
Featured Replacement: Titan 800-300 Fluid Section
The Titan 800-300 Fluid Section is listed on the 1140i main assembly page. Its dedicated product listing describes a complete fluid section assembly for compatible sprayer configurations.
Compare the assembly with your installed pump and review the supplied contents before purchasing. Inspection of the existing pump can help establish whether individual service parts or a complete replacement assembly are appropriate.
Build an Accurate Repair Parts List
Record the diagram reference, manufacturer part number, and required quantity for each component. Inspect adjacent parts during service so that worn mating surfaces, damaged hardware, or missing seals can be addressed in the same repair.
Follow the sprayer manual’s pressure-relief, power-disconnection, and service procedures before working on the equipment. Diagnose the cause of a problem before ordering; similar symptoms can arise from different components.
Get Help Selecting Your 1140i Parts
Have your model, serial number, cart configuration, and diagram reference ready. Call AllTitanParts for assistance matching the replacement part to your sprayer before checkout.
Call 713-931-0006Frequently Asked Questions
How do I identify the correct Titan 1140i replacement part?
Confirm your model, serial number, and equipment configuration. Match the relevant assembly diagram callout to its listed part number, then review the product’s compatibility and contents.
Which parts sections are available for the 1140i?
The category includes main, drive, fluid section, filter, and PRIME/SPRAY valve assemblies, High Rider and Low Rider carts, a Low Rider siphon set, and accessories.
Which cart references appear in the 1140i category?
The High Rider cart section uses assembly reference 800-600, and the Low Rider cart section uses 800-590. Select the diagram matching your installed cart.
Is the Titan 800-300 fluid section listed for the 1140i?
Yes. Titan 800-300 appears on the 1140i main assembly page, and the category includes a dedicated fluid section diagram for that assembly. Confirm fitment against your installed pump before ordering.
Are all components shown in an assembly diagram included with one purchase?
No. Diagrams show component positions and identification references. Each product listing specifies the supplied item or assembly; additional components may need to be ordered separately.
