Titan EPX2155 Piston Pump Parts
Shop Titan EPX2155 Piston Pump Parts for maintenance, troubleshooting and repair of the airless sprayer's pumping system. Use the applicable EPX2155 exploded parts diagram to identify piston components, packings, inlet and outlet valve parts, seals, O-rings, fittings and related pump components by exact callout and replacement part number.
Find Titan EPX2155 Piston Pump Replacement Parts
The piston pump is a central part of the Titan EPX2155 fluid-delivery system. Its internal components work together to draw coating material from the supply, move it through the pump and deliver pressurized fluid toward the downstream spray system.
Worn packings, damaged sealing components, contaminated valve areas or wear within the pump can contribute to difficult priming, reduced output, pressure loss, fluid leakage or inconsistent material delivery. Correct diagnosis and accurate parts identification help avoid unnecessary replacement of unrelated components.
How to Find the Correct EPX2155 Piston Pump Part
Confirm EPX2155
Verify that the sprayer being serviced is the Titan EPX2155 and identify the applicable machine configuration.
Open the Pump Diagram
Use the applicable EPX2155 piston pump exploded illustration to locate the internal or external pump component requiring service.
Match the Callout
Match the numbered diagram callout to the corresponding part description and replacement part number in the parts list.
Verify Part & Quantity
Confirm the exact replacement part number, description and required quantity before ordering.
How the EPX2155 Piston Pump Moves Coating Material
During operation, the pump's reciprocating components create the fluid movement needed to draw material into the pump and move it toward the pressurized outlet. Packings and sealing components help control fluid around the moving pump parts, while inlet and outlet valve components control the direction of material flow.
Piston Components
The piston and related moving components create the reciprocating pumping action required to move coating material through the pump.
Packings & Seals
Pump packings and applicable seals help control fluid around moving components and maintain the conditions needed for effective pumping.
Inlet Valve Components
The applicable inlet valve components support one-way material flow into the pump during the pumping cycle.
Outlet Valve Components
Outlet-side valve components help direct pumped coating material toward the pressurized fluid path of the sprayer.
EPX2155 Piston Pump Components to Inspect
Inspect diagram-listed piston components for wear, scoring, coating buildup or physical damage that can affect pumping performance.
Worn pump packings can contribute to leakage, pressure loss and reduced pumping efficiency.
Inspect applicable inlet valve components for contamination, wear or damage when the pump has difficulty drawing coating material.
Check outlet-side valve components when the pump cannot maintain normal fluid delivery or pressure.
Inspect applicable seals and O-rings for cuts, flattening, deterioration or damage that may allow fluid leakage.
Verify diagram-listed fittings, retainers and related pump hardware for damage, looseness, contamination or missing components.
Diagnose EPX2155 Piston Pump Problems
Priming, pressure and fluid-delivery problems can originate in several areas of an airless sprayer. Inspect the material supply and suction path before disassembling the piston pump, then evaluate the pump and downstream fluid system as needed.
1. Check Material Supply
Confirm adequate coating material and verify that the suction path is not restricted or drawing unwanted air.
2. Inspect Inlet Components
Check the applicable inlet valve components for contamination, wear or conditions that prevent proper material intake.
3. Inspect Packings & Piston
Look for leakage and signs of packing or piston wear that can reduce pump efficiency or pressure performance.
4. Check Outlet & Fluid Path
Inspect outlet-side pump components and downstream fluid-system parts when material intake is normal but pressure or output remains poor.
Common Titan EPX2155 Piston Pump Problems
These symptoms can help narrow the inspection area, but they do not automatically confirm a failed pump component. Diagnose the surrounding fluid system before ordering replacement parts.
| Symptom | What to Inspect | Repair Direction |
|---|---|---|
| Pump Will Not Prime | Material supply, suction path and applicable inlet valve components. | Eliminate suction restrictions or air leaks, then inspect inlet-side pump components. |
| Reduced Pump Output | Packings, piston components, inlet and outlet valve areas. | Inspect for wear, contamination or internal leakage before selecting replacement parts. |
| Cannot Maintain Pressure | Pump valves, packings, piston components and downstream fluid system. | Determine whether pressure loss is internal to the pump or elsewhere in the fluid path. |
| Fluid Leakage at Pump | Packings, seals, O-rings, fittings and mating surfaces. | Relieve pressure, identify the exact leak source and replace the verified worn or damaged components. |
| Inconsistent Material Delivery | Material supply, suction path, pump valves, packings and downstream fluid path. | Diagnose the complete fluid path before determining which pump component requires service. |
Piston Pump or Another EPX2155 Repair Area?
EPX2155 Piston Pump
Start here for piston components, packings, inlet and outlet valve parts, seals, O-rings, fittings and related pump components.
EPX2155 Fluid Section
Use the applicable fluid-section diagram when identifying internal pump components and related repair parts.
EPX2155 Drive System
If the pump is not being mechanically driven correctly, inspect the applicable drive components before rebuilding the pump.
EPX2155 Main Assembly
Use the applicable main assembly diagram for components outside the piston pump and its internal fluid section.
Verify EPX2155 Piston Pump Part Compatibility
Do not select a piston, packing, valve component, seal, O-ring, fitting or other pump part based only on appearance. Similar pump components used on Titan and SprayTech machines can differ by pump configuration, dimensions, sealing arrangement or application.
Confirm the EPX2155 model, applicable machine configuration, correct piston pump diagram, numbered callout, component description, exact replacement part number and required quantity before ordering. Do not assume interchangeability with the EPX2255, EPX2355, EPX2455, EPX2555 or another sprayer unless the applicable parts information confirms compatibility.
Before Buying Titan EPX2155 Piston Pump Parts
Verify the exact sprayer model and applicable pump configuration.
Determine whether the issue involves priming, output, pressure, leakage or inconsistent fluid delivery.
Check mating surfaces and related pump components when wear or damage is found.
Match the required component to its numbered callout in the applicable EPX2155 parts diagram.
Confirm the exact replacement part number, description and quantity before ordering.
Find Titan EPX2155 Piston Pump & Related Parts
Use the EPX2155 piston pump diagram for pump-related components and repair parts. For other Titan SprayTech Advantage EPX models, select the appropriate model and assembly before ordering to help ensure accurate part identification.
Relieve Pressure Before EPX2155 Piston Pump Service
Shut down the sprayer, disconnect or isolate the applicable power supply and follow the manufacturer's complete pressure-relief procedure before servicing the piston pump. Never loosen a pressurized hose, fitting, valve, filter or pump component. Follow the applicable Titan service instructions for pump removal, disassembly, cleaning, inspection, replacement, reassembly and testing.
Shop Titan EPX2155 Piston Pump Parts
Use the applicable EPX2155 piston pump exploded diagram to identify the piston component, packing, valve part, seal, O-ring, fitting or related pump component you need, then verify the exact replacement part number and required quantity before ordering.
Shop EPX2155 Piston Pump PartsTitan EPX2155 Piston Pump Parts FAQ
What does the Titan EPX2155 piston pump do?
The piston pump draws coating material into the pumping system and moves it toward the pressurized fluid path used by the airless spray system.
How do I identify the correct EPX2155 pump part?
Confirm the EPX2155 model and applicable configuration, open the correct piston pump diagram and match the numbered callout to the exact replacement part number, description and quantity.
What should I inspect if my EPX2155 will not prime?
Check the coating supply, suction path and applicable inlet valve components first. Air leaks, restrictions and contamination can produce priming symptoms similar to internal pump wear.
Can worn EPX2155 pump packings cause pressure loss?
Worn sealing components can contribute to internal or external leakage and reduced pumping efficiency. Pump valves and other pressure-system components should also be inspected before the repair is confirmed.
What should I check if the EPX2155 piston pump leaks?
After fully relieving system pressure, inspect the applicable packings, seals, O-rings, fittings and mating surfaces to determine the exact source of leakage.
Are EPX2155 and EPX2255 piston pump parts interchangeable?
Do not assume interchangeability between EPX models. Compare the applicable exploded diagrams and exact replacement part numbers before using a component listed for another model.
What should I verify before ordering EPX2155 piston pump parts?
Confirm the EPX2155 model, applicable machine configuration, correct piston pump diagram, numbered callout, component description, exact replacement part number and required quantity.
Need Help Finding an EPX2155 Piston Pump Part?
Have your EPX2155 model information, machine configuration, serial number when available, existing part number and exploded-diagram callout ready to help identify the correct piston component, packing, valve part, seal, O-ring, fitting or related replacement pump component.
Parts & Fitment Help: 713-931-0006
