Pump Head Assembly Overview
Buy Genuine Titan ED655 Plus Pump Head Replacement Parts
The Titan ED655 Plus Pump Head Assembly is the fluid-handling section of the ED655 Plus airless sprayer. Working with the hydraulically actuated diaphragm pump, the pump head helps control coating intake, priming, fluid direction and pressurized material delivery to the spray hose.
Its inlet and outlet check valves help regulate the direction of coating movement. The prime/spray valve provides the designated fluid routing required during priming and spraying, while seals, washers, valve seats and fittings help maintain properly assembled fluid connections.
AllTitanParts lists individual components for this assembly, including the 0278242 Inlet Valve Assembly, 0278334 Paint Pump Block, 0555850 Prime/Spray Valve Assembly, 0278241 Ball Cage Seat Assembly, 0093635 Outlet Ball and 0278335 Outlet Fitting. Select the replacement part by its exact OEM number and factory diagram position.
OEM Parts Directory
Titan ED655 Plus Pump Head Assembly Parts List
The following 16 parts are listed for the Titan ED655 Plus Pump Head Assembly. Use the corresponding diagram references to locate the component and confirm its OEM part number before ordering.
| Diagram Ref. | Titan OEM Part Number | Part Description | Repair Function |
|---|---|---|---|
| 1 | 0278242 | Inlet Valve Assembly | Controls coating entry into the pump head. |
| 2 | 0089482 | Nylon Sealing Washer | Provides sealing at its specified connection. |
| 3 | 0278334 | Paint Pump Block | Forms the main structural body of the fluid pump head. |
| 4 | 0555850 | Prime/Spray Valve Assembly | Controls the designated priming and spraying fluid paths. |
| 5 | 0278362 | Washer | Supports correct spacing or component seating. |
| 6 | 0278241 | Ball Cage Seat Assembly | Provides seating and retention within the valve mechanism. |
| 7 | 0093635 | Outlet Ball | Helps control reverse flow at the outlet check valve. |
| 8 | 0047485 | Outlet Spring | Provides spring force within the outlet valve mechanism. |
| 9 | 0278361 | Ball Guide | Guides the outlet valve ball during operation. |
| 10 | 9871114 | O-Ring | Seals its designated pump head connection. |
| 11 | 0278335 | Outlet Fitting | Provides the specified fluid outlet connection. |
| 12 | 0278337 | Pusher Body | Supports the pump head's pusher mechanism. |
| 13 | 0278250 | Pusher Stem Assembly | Forms part of the pusher actuation mechanism. |
| 14 | 0278368 | Pusher Spring | Provides return or operating force to the pusher. |
| 15 | 0156646 | Seal | Helps prevent leakage at the designated fluid passage. |
| 16 | 0278340 | Pusher Washer or Disk | Supports force transfer within the pusher assembly. |
The catalog displays 0278241 and 0278250 in product titles but shortens their part-number fields to 278241 and 278250. Confirm the leading-zero format against the factory diagram before purchase.
Featured OEM Pump Head Components
Shop Titan ED655 Plus Inlet Valves, Outlet Balls, Prime/Spray Valves and Seals
Titan 0278242 Inlet Valve Assembly
The Titan 0278242 Inlet Valve Assembly helps control coating entry into the ED655 Plus pump head. Correct inlet valve operation is important for priming and consistent material intake.
Inspect this assembly when the pump has difficulty drawing material or when inlet valve leakage is suspected.
OEM Part Number: 0278242Titan 0278334 Paint Pump Block
The Titan 0278334 Paint Pump Block provides the main fluid-handling body and mounting structure for important pump head components.
Inspect the block's passages, threaded connections and sealing surfaces when diagnosing structural damage, contamination or persistent leakage.
OEM Part Number: 0278334Titan 0555850 Prime/Spray Valve Assembly
The Titan 0555850 Prime/Spray Valve Assembly directs coating through the designated fluid path during priming and spraying operations.
A damaged or malfunctioning prime/spray valve may contribute to priming difficulties, unexpected return flow or pressure loss. Follow the Titan diagnostic procedure before replacement.
OEM Part Number: 0555850Titan 0278241 Ball Cage Seat Assembly
The Titan 0278241 Ball Cage Seat Assembly provides important seating and retention functions within the pump head valve mechanism.
Wear, contamination or damage to a valve seat can affect proper check valve sealing and fluid control.
OEM Part Number: 0278241Titan 0093635 Outlet Ball
The Titan 0093635 Outlet Ball forms part of the outlet check valve. It helps permit fluid discharge while limiting unwanted reverse flow when properly seated.
Inspect the ball and mating seat for contamination or wear when diagnosing pressure instability or poor pump output.
OEM Part Number: 0093635Titan 0047485 Outlet Spring
The Titan 0047485 Outlet Spring supplies spring force within the outlet check valve assembly.
A damaged or incorrectly installed spring can interfere with valve operation. Inspect it together with the outlet ball, guide and seat.
OEM Part Number: 0047485Titan 0278361 Ball Guide
The Titan 0278361 Ball Guide helps guide and retain the outlet ball within the check valve mechanism.
Check the guide for damage or obstruction when servicing the outlet valve components.
OEM Part Number: 0278361Titan 0278335 Outlet Fitting
The Titan 0278335 Outlet Fitting provides the specified connection between the pump head outlet and the downstream fluid delivery system.
Inspect its threads, sealing surfaces and connection condition when troubleshooting leakage at the fluid outlet.
OEM Part Number: 0278335Pump Head System Functions
How the ED655 Plus Pump Head Assembly Supports Sprayer Performance
Material Intake
The inlet valve controls coating entry into the pump head during the pumping cycle.
Priming and Fluid Routing
The prime/spray valve directs fluid through the appropriate path for priming or spraying.
Outlet Check Control
The outlet ball, seat, spring and guide help control discharge and resist reverse fluid movement.
Sealing and Delivery
Seals, washers, the pump block and outlet fitting support fluid containment and delivery.
Troubleshooting and Repair
Common Titan ED655 Plus Pump Head Problems
The following symptoms may have more than one cause. Use Titan's troubleshooting instructions to identify the actual fault before ordering replacement parts.
| Observed Problem | Components to Inspect | Recommended Check |
|---|---|---|
| Pump will not prime | 0278242, 0555850 and material supply | Check inlet valve operation, prime/spray routing and the supply path for restrictions or air entry. |
| Pressure will not build | 0093635, 0278241, 0047485, 0555850 | Inspect outlet check valve seating and prime/spray valve function. |
| Pressure fluctuates | 0093635, 0278361, 0278242 and diaphragm pump | Inspect valve movement, seating surfaces and the hydraulic drive system. |
| Fluid leaks around pump head | 0089482, 9871114, 0156646 and connections | Identify the exact leak location and inspect the appropriate seal or washer. |
| Fluid leaks at outlet connection | 0278335 and related sealing components | Check fitting condition, correct assembly and connection sealing. |
| Outlet valve does not operate smoothly | 0093635, 0047485, 0278361, 0278241 | Inspect the outlet ball, spring, guide and seat for contamination or damage. |
| Pusher mechanism sticks | 0278337, 0278250, 0278368, 0278340 | Have the pusher mechanism inspected for wear, contamination or damaged components. |
OEM Part Number Reference
Identify the Correct Titan ED655 Plus Pump Head Components
Several pump head components have similar functions but different OEM part numbers. For example, Titan 0093635 is the Outlet Ball, 0047485 is the Outlet Spring, 0278361 is the Ball Guide and 0278241 is the Ball Cage Seat Assembly.
These components should not be treated as interchangeable. Use the factory diagram to identify the correct item, and inspect associated valve components when performing a complete outlet check valve repair.
OEM Buying Guide
How to Choose the Correct Titan ED655 Plus Pump Head Part
Verify Your Sprayer
Confirm that your equipment is a Titan ED655 Plus and check its model and serial information.
Locate the Pump Head
Open the ED655 Plus Pump Head Assembly exploded diagram and find the component reference.
Match the Part Number
Compare the diagram callout, component description and complete Titan OEM part number.
Order the Replacement
Select the matching replacement component and follow Titan's installation and service instructions.
Preventive Maintenance
Maintain Your Titan ED655 Plus Pump Head Assembly
Inspect the Inlet Valve
Check the 0278242 Inlet Valve Assembly when diagnosing poor material intake or difficulty priming.
Maintain Outlet Check Components
During authorized service, inspect the outlet ball, spring, guide and valve seat for wear or contamination.
Check Seals and Washers
Examine the 0089482 Nylon Sealing Washer, 9871114 O-Ring and 0156646 Seal at their specified locations.
Clean and Flush Properly
Follow Titan's cleaning procedures to reduce coating buildup and contamination in the pump head and valve passages.
Related Titan ED655 Plus Assemblies
Shop More Titan ED655 Plus Airless Pump Parts
ED655 Plus Main Assembly
Find main assembly hardware, structural components and related replacement parts.
ED655 Plus Diaphragm Pump
Browse hydraulic pistons, diaphragms, pressure regulating components, seals and drive parts.
ED655 Plus Hopper Assembly
Explore hopper components and material supply parts for the ED655 Plus.
Titan ED655 Plus Airless Pump Parts
Explore all four ED655 Plus assembly categories and their parts diagrams.
Titan ED655 Plus Pump Head Service Safety
Before removing or replacing pump head components, switch off the sprayer, disconnect electrical power and follow Titan's complete pressure-relief procedure. Never loosen pressurized fittings or attempt to stop a high-pressure fluid leak with your hand. Fluid injection injuries require immediate emergency medical attention. Inspect all valve components, seals and fluid connections before restarting the sprayer.
Genuine Titan ED655 Plus Pump Head Parts
Order Titan ED655 Plus Pump Head Assembly Parts Today
Shop genuine Titan inlet valve assemblies, paint pump blocks, prime/spray valves, outlet balls, springs, ball guides, O-rings, seals and fittings for the ED655 Plus Pump Head Assembly.
Shop ED655 Plus Pump Head PartsFrequently Asked Questions
Titan ED655 Plus Pump Head Assembly FAQ
What is the Titan ED655 Plus Pump Head Assembly?
It is the fluid-handling assembly that contains components for coating intake, priming, outlet check valve operation, sealing and fluid delivery.
How many parts are listed for the ED655 Plus Pump Head Assembly?
The AllTitanParts category currently lists 16 individual OEM components for this assembly.
What is the Titan ED655 Plus Inlet Valve Assembly part number?
Titan 0278242 is the Inlet Valve Assembly listed for the ED655 Plus Pump Head Assembly.
What is the Titan ED655 Plus Paint Pump Block part number?
Titan 0278334 is the Paint Pump Block identified in the pump head parts directory.
Which Prime/Spray Valve Assembly is listed for the ED655 Plus?
Titan 0555850 is the Prime/Spray Valve Assembly listed for this pump head.
What is the Titan ED655 Plus Outlet Ball part number?
Titan 0093635 is the Outlet Ball listed for the pump head outlet valve mechanism.
What outlet spring is used in the ED655 Plus Pump Head?
Titan 0047485 is the Outlet Spring listed for this assembly.
Why is my Titan ED655 Plus not priming?
Possible causes include inlet valve contamination, prime/spray valve problems, a restricted coating supply or an air leak. Diagnose the complete system before replacing parts.
Can a worn outlet ball cause pressure problems?
Yes. An outlet ball or seat that does not seal correctly can contribute to pressure loss or irregular pump operation.
What seals are listed for the ED655 Plus Pump Head?
Listed sealing components include Titan 0089482 Nylon Sealing Washer, 9871114 O-Ring and 0156646 Seal.
Are ED655 and ED655 Plus Pump Head parts interchangeable?
Compatibility should not be assumed. Verify the exact model, serial number, parts diagram and OEM component number before purchasing.
Where can I buy Titan ED655 Plus Pump Head Assembly parts?
Shop Titan ED655 Plus Pump Head Assembly Parts at AllTitanParts. For help identifying a replacement component, call 713-931-0006.
Titan OEM Parts Assistance
Need Help Finding ED655 Plus Pump Head Parts?
Have your Titan ED655 Plus model, serial number and factory pump head diagram reference ready when requesting assistance with OEM part identification or compatibility.
713-931-0006
