Genuine Titan OEM | Fluid Filtration Parts
Shop Titan EPX2555 Filter Assembly Parts
Keep your airless sprayer's fluid system properly maintained with Titan EPX2555 Filter Assembly Parts (0507203) from AllTitanParts. Shop genuine OEM filter bodies, 50-mesh filters, filter supports, O-rings, pressure transducers, bypass valves and related components. Whether you are replacing a clogged filter, repairing a leaking seal or diagnosing pressure control problems, find the correct part using the EPX2555 factory exploded diagram.
Filter Assembly Overview
Buy Genuine Titan EPX2555 Filter Assembly Replacement Parts
The Titan EPX2555 Filter Assembly (0507203) is an important part of the sprayer's fluid delivery and pressure management system. Its filter element helps capture particles and debris before they travel farther downstream toward the spray hose, gun and spray tip.
Effective filtration helps reduce contamination-related spray tip blockages and supports more consistent material flow. The filter body, support and O-ring work together to position the filter element and seal the specified fluid connections.
This assembly category also includes a pressure transducer, filter/bypass sensor housing, inner transducer seal and bypass valve assembly. These components serve different functions from the filter element. The transducer is associated with pressure sensing, while the bypass valve provides a designated fluid diversion function during priming and pressure relief.
AllTitanParts lists eight individual OEM components for this assembly. Review the numbered diagram and part descriptions to identify the correct replacement before ordering.
OEM Parts Directory
Titan EPX2555 Filter Assembly Parts List
The following eight parts are listed for the EPX2555 Filter Assembly. Use the diagram reference, OEM part number and component description to identify the correct replacement.
| Diagram Ref. | Titan OEM Part Number | Part Description | Primary Function |
|---|---|---|---|
| 1 | 0294194 | Filter Body Assembly, replaces 755-190 | Houses and supports the fluid filtration components. |
| 2 | 14069 | 50 Mesh Filter | Captures debris and particles in the coating flow. |
| 3 | 9894245 | Filter Support | Supports the filter element in its designated position. |
| 4 | 0014072 | O-Ring, listed as Titan 14072 | Seals the specified filter assembly connection. |
| 7 | 0551666 | Complete Transducer | Provides pressure sensing for the applicable control system. |
| 8 | 0555625 | Filter/Bypass Sensor Housing | Provides the specified housing for filter and bypass-related components. |
| 10 | 800-911 | Inner Transducer Seal, replaces 0507984 | Provides sealing at the designated transducer location. |
| 11 | 0507690 | Bypass Valve Assembly | Controls the specified bypass fluid path. |
Part-number note: The O-ring product title uses 14072, while the catalog part-number field identifies 0014072. Confirm the correct ordering number when purchasing.
Featured OEM Components
Shop Titan EPX2555 Filters, Transducers, Seals and Bypass Valves
Titan 0294194 Filter Body Assembly
The Titan 0294194 Filter Body Assembly provides the main housing for the specified filtration components. Its condition is important for maintaining secure connections and supporting the filter element.
Inspect the housing for damaged threads, cracks, corrosion or damaged sealing surfaces when repairing persistent leaks.
OEM Part Number: 0294194 | Replaces 755-190Titan 14069 50 Mesh Filter
The Titan 14069 Filter is a 50-mesh element designed to capture particles in the coating material. The filter helps protect downstream components from debris that may contribute to spray tip blockage.
Inspect and clean the filter according to Titan's instructions. Replace it when damaged or no longer serviceable.
OEM Part Number: 14069 | 50 MeshTitan 9894245 Filter Support
The Titan 9894245 Filter Support helps hold the filter element in its intended position within the assembly.
Inspect the support when replacing the filter or when internal filtration components appear loose, damaged or incorrectly positioned.
OEM Part Number: 9894245Titan 14072 O-Ring
The Titan 14072 O-Ring provides a seal at its specified fluid system connection. A damaged or improperly seated O-ring can contribute to fluid leakage.
The catalog lists 0014072 as the part number. Match the correct sealing component before ordering.
Catalog Part Number: 0014072Titan 0551666 Complete Transducer
The Titan 0551666 Complete Transducer is a pressure-sensing component associated with the sprayer's control system.
If the sprayer displays abnormal pressure regulation, the transducer and related electrical components should be evaluated using the applicable Titan diagnostic procedure.
OEM Part Number: 0551666Titan 0555625 Filter/Bypass Sensor Housing
The Titan 0555625 Housing is listed as a filter/bypass sensor housing for the EPX2555 assembly.
Inspect the housing when servicing the filter, transducer or bypass system, particularly if there is visible damage or a confirmed leak at the housing.
OEM Part Number: 0555625Titan 800-911 Inner Transducer Seal
The Titan 800-911 Inner Transducer Seal is a replacement sealing component for the designated transducer location.
The catalog identifies 800-911 as replacing Titan 0507984. Use the specified replacement to maintain the intended seal.
OEM Part Number: 800-911 | Replaces 0507984Titan 0507690 Bypass Valve Assembly
The Titan 0507690 Bypass Valve Assembly controls the designated fluid bypass path used in the sprayer's priming and pressure-relief functions.
Inspect the bypass valve when the sprayer has difficulty switching between priming and spraying or when bypass leakage is suspected.
OEM Part Number: 0507690Assembly Functions
How the Titan EPX2555 Filter Assembly Works
Fluid Filtration
The 50-mesh filter captures particles that could otherwise pass through the fluid delivery system.
Filter Positioning
The filter body and support help maintain the correct placement of the filtration element.
Pressure Sensing
The transducer supplies pressure-related information to the applicable control system.
Bypass Control
The bypass valve manages the designated fluid diversion path during applicable operating procedures.
Troubleshooting and Repair
Common Titan EPX2555 Filter Assembly Problems
Filter restrictions, worn seals and pressure control problems can produce similar symptoms. Use the appropriate Titan diagnostic procedure before replacing components.
| Observed Problem | Components to Inspect | Recommended Check |
|---|---|---|
| Reduced fluid flow | 14069 Filter | Inspect for excessive debris or blockage and service according to Titan instructions. |
| Fluid leaks around filter housing | 0294194 Filter Body and 0014072 O-Ring | Check the sealing surfaces, O-ring condition and housing integrity after pressure relief. |
| Filter element sits incorrectly | 9894245 Filter Support | Inspect the support and confirm the correct filter installation. |
| Inconsistent pressure regulation | 0551666 Transducer and control system | Diagnose pressure sensing and associated electrical components before replacing the transducer. |
| Leak near transducer | 800-911 Seal and 0555625 Housing | Inspect the specified seal and housing for damage or incorrect assembly. |
| Difficulty switching between prime and spray | 0507690 Bypass Valve Assembly | Inspect the bypass valve and related fluid passages according to the service manual. |
OEM Replacement Reference
Titan EPX2555 Filter Assembly Part Number Cross-References
The filter assembly category is identified by 0507203. The AllTitanParts catalog lists these additional part-number relationships:
- 0294194 Filter Body Assembly replaces 755-190.
- 800-911 Inner Transducer Seal replaces 0507984.
- 0014072 is the catalog ordering number for the product titled Titan 14072 O-Ring.
These references apply only to the components identified. Confirm the correct part and sprayer configuration before ordering.
OEM Buying Guide
How to Choose the Correct Titan EPX2555 Filter Assembly Part
Confirm Your Model
Verify your Titan EPX2555 model and check its serial number or configuration.
Locate the Diagram Reference
Find the required component in the Filter Assembly 0507203 exploded view.
Verify the OEM Number
Match the part number and check for any documented replacement or supersession.
Order the Right Component
Select the correct OEM replacement and follow Titan's installation procedure.
Preventive Maintenance
Maintain Your Titan EPX2555 Filter Assembly
Inspect the Filter Element
Check the 50-mesh filter for accumulated debris and clean or replace it as specified by Titan.
Check O-Rings and Seals
Inspect sealing components during authorized maintenance and replace damaged parts with the correct OEM items.
Monitor Pressure Performance
Investigate unusual pressure behavior and have the transducer and control system checked when required.
Maintain the Bypass Valve
Follow the manufacturer cleaning and inspection instructions to help prevent contamination-related valve problems.
Related Titan EPX2555 Assemblies
Shop More Titan EPX2555 Piston Pump Parts
EPX2555 Main Assembly
Browse fluid hoses, fittings, bypass valves and other main assembly components.
EPX2555 Fluid Section Assembly
Find fluid section replacement parts for piston pump repairs.
EPX2555 Drive Assembly
Shop motors, gearboxes, sliders and electrical drive components.
EPX2555 Piston Pump Parts
Explore the complete range of EPX2555 replacement assembly categories.
Titan EPX2555 Filter Assembly Service Safety
Before opening the filter housing, removing a filter or servicing the transducer or bypass valve, switch off the sprayer, disconnect electrical power and follow Titan's complete pressure-relief procedure. Never loosen a pressurized filter housing or fluid connection. High-pressure fluid injection injuries require immediate emergency medical attention. Electrical pressure control repairs should be performed by qualified personnel using the applicable Titan service instructions.
Genuine Titan EPX2555 Filter Assembly Parts
Order Titan EPX2555 Filter Assembly Parts Today
Shop OEM filter elements, filter bodies, supports, O-rings, pressure transducers, seals and bypass valves. Find the right replacement for your Titan EPX2555 using the factory parts diagram.
Shop EPX2555 Filter Assembly PartsFrequently Asked Questions
Titan EPX2555 Filter Assembly FAQ
What is the Titan EPX2555 Filter Assembly?
It is the assembly identified as 0507203, containing fluid filtration and related pressure sensing and bypass components for the EPX2555 piston pump.
What is the Titan EPX2555 Filter Assembly number?
The assembly is identified as Titan 0507203.
How many parts are listed for the EPX2555 Filter Assembly?
The AllTitanParts category currently lists eight individual replacement parts.
What is the EPX2555 50-mesh filter part number?
Titan 14069 is the 50-mesh filter listed at diagram reference 2.
What filter body replaces Titan 755-190?
Titan 0294194 Filter Body Assembly is listed as replacing Titan 755-190.
What is the Titan EPX2555 Filter Support part number?
Titan 9894245 is the Filter Support listed at diagram reference 3.
What is the EPX2555 Filter Assembly O-ring part number?
The product is titled Titan 14072 O-Ring, and its catalog part-number field is 0014072.
What is the Titan EPX2555 Transducer part number?
Titan 0551666 is the Complete Transducer listed for the assembly.
What part replaces Titan 0507984?
Titan 800-911 Inner Transducer Seal is listed as replacing Titan 0507984.
What is the EPX2555 Bypass Valve Assembly part number?
Titan 0507690 is the Bypass Valve Assembly listed at diagram reference 11.
Can a clogged filter cause poor spray performance?
Yes. A restricted filter can reduce material flow and contribute to poor spray performance. Other causes should also be evaluated before replacing components.
Where can I buy Titan EPX2555 Filter Assembly parts?
Shop Titan EPX2555 Filter Assembly Parts at AllTitanParts. For part identification assistance, call 713-931-0006.
Titan OEM Parts Assistance
Need Help Finding EPX2555 Filter Assembly Parts?
Have your Titan EPX2555 model, serial number, assembly reference and exploded diagram position ready when requesting assistance with OEM part identification.
