Titan 9894245 Filter Support
OEM SprayTech Filtration Component
Titan 9894245 Filter Support is a genuine OEM structural component that holds the fluid filter in position within the pump manifold or filter housing on compatible SprayTech LCX, GPX, and Airless EPX/EP sprayers. It prevents filter collapse under pressure and maintains proper alignment for reliable filtration.
Compatibility
Inspect the filter support for cracks, warping, or damage during filter maintenance. Clean the filter cavity thoroughly. Install with correct orientation (often marked) and ensure the filter seats fully against the support. Replace the filter element at the same time for best results.
Titan Filtration Replacement Component
Titan 9894245 Filter Support for SprayTech Airless Sprayers
Titan 9894245 is an OEM filter support that secures and positions the fluid filter within the pump manifold or filter housing. It prevents the filter from collapsing under pressure and ensures all paint passes through the screen for full filtration. A damaged or missing filter support allows the filter to deform or shift, leading to reduced filtration efficiency and debris reaching the spray tip. The official Titan EP2300 manual lists 9894245 as "Support, Filter" in the Dump Valve Assembly, confirming its role in the filtration system.
| Detail | Technical / Commercial Information |
|---|---|
| Product Overview | Genuine OEM filter support. Confirmed in the official Titan EP2300 manual as "Support, Filter". Also identified by Fix.com and eReplacementParts for a broad range of EP, EPX, LC, and GPX series models. |
| Function | Secures filter element in correct position under pressure; prevents filter collapse; ensures full filtration by forcing all paint through the screen; maintains proper alignment against sealing surfaces. |
| Compatible Models | SprayTech EP2005, EP2105, EP2205, EP2300, EP2300se, EP2400, EP2510; EPX2305, EPX2405, EPX2455, EPX2505, EPX2555; GPX750, GPX1250, GPX1600; LC750, LC1250, LC1600; Titan Linecrew 750, 1600. Also cross-referenced for Wagner/Sherwin-Williams SW319. Always verify fitment using the correct parts diagram. |
| OEM Part Number | 9894245 Filter Support. |
| Replacement Indicators | Filter collapse under pressure; filter bypass; debris reaching spray tip; reduced filtration efficiency; flow blockage; cracks, warping, or damage to the support found during filter maintenance. |
| Related Parts Commonly Serviced Together | Filter element / screen; housing O-ring / gasket; filter housing / cap. |
| Why Genuine OEM | Precision-molded construction ensures correct fit and proper filter retention. Using the specified support prevents bypass and debris damage, ensuring consistent paint quality and extending equipment life. |
Service guidance: Inspect the filter support for cracks, warping, or damage during filter maintenance. Clean the filter cavity thoroughly. Install the new support with correct orientation (often marked). Ensure the filter seats fully against the support. Replace the filter element at the same time for best results. Always relieve system pressure and disconnect power before servicing. Note: Some parts databases label this component as a "Core Spring," but the official Titan manual and Bedford Precision identify it as a filter support.
Frequently Asked Questions
Quick answers for confirming fitment and identifying when replacement is needed.
