Titan EPX2155 Suction Set Assembly Parts (P/N 0551104)
Shop Titan EPX2155 Suction Set Assembly Parts (P/N 0551104) for maintenance and repair of the material-intake system. Use the applicable EPX2155 exploded parts diagram to identify suction components, intake tubing or hoses, fittings, connectors, strainers and related hardware by exact callout, description and replacement part number.
Find EPX2155 Suction Set Assembly 0551104 Replacement Parts
The suction set forms the material-intake path between the coating supply and the sprayer's piston pump. During priming and normal operation, the pump must be able to draw material through this intake path without excessive restriction or unwanted air entering the system.
A damaged suction component, restricted strainer, loose connection or compromised intake seal can contribute to difficult priming, intermittent material flow, pressure fluctuation or reduced pump output. Inspect the complete suction path before assuming that a priming problem requires internal piston-pump repair.
How to Find the Correct EPX2155 Suction Set Part
Confirm EPX2155
Verify the sprayer model and confirm that the applicable suction set is identified as P/N 0551104.
Open the Suction Diagram
Use the applicable EPX2155 Suction Set Assembly exploded illustration to locate the intake component requiring service.
Match the Callout
Match the numbered diagram callout to its corresponding description and replacement part number in the parts list.
Verify Part & Quantity
Confirm the exact replacement part number, description and required quantity before ordering.
How the EPX2155 Suction Set Supplies the Piston Pump
The suction set allows coating material to travel from the supply container to the pump inlet. Reliable intake depends on an unrestricted material path, secure connections and serviceable sealing components. Problems anywhere along this path can interfere with priming and normal pump performance.
Suction Components
The intake components provide the path used to draw coating material from the supply container toward the piston pump.
Strainer Components
An applicable inlet strainer helps reduce the entry of larger debris into the material-intake path and pump.
Seals & Connections
Serviceable intake connections help prevent unwanted air from entering the suction path during pump operation.
Pump Inlet Connection
The suction assembly connects the coating supply path to the pump inlet so material can enter the fluid section.
EPX2155 Suction Set Components to Inspect
Inspect the diagram-listed material-intake path for cracks, damage, restrictions, deterioration or other conditions that can interfere with material flow.
Check the applicable strainer for dried coating, debris, physical damage or restriction that can limit material intake.
Inspect fittings and connectors for looseness, damaged threads, cracks or conditions that may allow air into the suction path.
Inspect applicable sealing components for cuts, flattening, deterioration or incorrect seating.
Check the connection between the suction set and pump inlet for looseness, contamination, damage or sealing problems.
Verify that diagram-listed clamps, retainers and related hardware are present, serviceable and correctly positioned.
Diagnose EPX2155 Priming and Material-Intake Problems
When an EPX2155 is difficult to prime, begin at the material supply and work toward the piston pump. This inspection sequence can help separate a suction-side problem from an internal pump problem.
1. Check Material Supply
Confirm adequate coating material and make sure the suction inlet is correctly positioned in the material supply.
2. Inspect the Strainer
Check the applicable inlet strainer for dried material, debris or restriction that can reduce material flow.
3. Check for Air Entry
Inspect suction connections, fittings and sealing components for looseness or damage that may allow unwanted air into the intake path.
4. Inspect the Pump
If the suction path is clear and properly sealed, continue diagnosis at the piston pump and applicable inlet valve components.
Common EPX2155 Suction Set Problems
Suction-side faults can resemble internal pump problems. Inspect the complete intake path and confirm that it is unrestricted and properly sealed before rebuilding the piston pump.
| Symptom | What to Inspect | Repair Direction |
|---|---|---|
| Sprayer Will Not Prime | Material level, strainer, suction path, fittings and pump inlet. | Remove restrictions and correct verified suction leaks before proceeding to internal pump diagnosis. |
| Intermittent Material Flow | Suction tube or hose, intake connections, strainer and material supply. | Check for restrictions, damaged intake components and unwanted air entering the system. |
| Reduced Pump Output | Inlet strainer, suction path, pump inlet connection and piston pump. | Restore unrestricted material intake, then inspect the pump if output remains reduced. |
| Air Appears in Material Flow | Fittings, connectors, seals and suction tube or hose. | Locate and correct the verified suction-side leak or damaged sealing component. |
| Frequent Intake Restriction | Strainer, coating condition and complete material-intake path. | Clean and inspect the applicable intake components and address the source of repeated contamination. |
Suction Set or Another EPX2155 Repair Area?
EPX2155 Suction Set 0551104
Start here for diagram-listed suction components, strainers, intake connections, fittings, seals and related material-intake parts.
EPX2155 Piston Pump
Inspect the piston pump when the suction path is clear and properly sealed but priming, pressure or material delivery remains abnormal.
View EPX2155 Piston Pump PartsEPX2155 Main Assembly
Use the Main Assembly diagram for general machine components, fittings, brackets, controls and related hardware.
View EPX2155 Main Assembly PartsEPX2155 Motor Assembly
Use the Motor Assembly diagram when diagnosis points to the electric motor, its mounting components or related connections.
View EPX2155 Motor Assembly PartsVerify EPX2155 Suction Set 0551104 Part Compatibility
Do not select a suction tube, hose, strainer, fitting, connector, seal or other intake component based only on appearance. Similar material-intake parts can differ by dimensions, connection style, sealing arrangement and sprayer configuration.
Confirm the EPX2155 model, P/N 0551104 where applicable, correct Suction Set Assembly diagram, numbered callout, component description, exact replacement part number and required quantity before ordering. Do not assume interchangeability with EPX2255, EPX2355, EPX2455, EPX2555 or another EPX-series sprayer unless the applicable parts information confirms compatibility.
Before Buying EPX2155 Suction Set Assembly Parts
Verify the exact sprayer model before selecting material-intake components.
Confirm the suction assembly reference before using its parts breakdown for component selection.
Check the strainer, suction path, fittings, connections and pump inlet before deciding which component requires replacement.
Match the required component to its numbered callout in the correct exploded diagram.
Confirm the exact replacement part number, description and quantity required before ordering.
Find EPX2155 Suction, Pump, Motor & Main Assembly Parts
Use the suction set diagram for material-intake components, then move to the piston pump, motor or main assembly diagram when diagnosis identifies another EPX2155 repair area.
Relieve Pressure Before EPX2155 Suction System Service
Shut down the sprayer, disconnect or isolate the applicable electrical supply and follow the manufacturer's complete pressure-relief procedure before servicing the suction set or piston pump. Never loosen a pressurized fluid component. Follow the applicable Titan service instructions for removal, cleaning, inspection, replacement, reassembly and testing.
Shop Titan EPX2155 Suction Set Assembly Parts
Use the applicable EPX2155 Suction Set Assembly diagram for P/N 0551104 to identify the suction component, strainer, fitting, connector, seal or related material-intake part you need. Verify the exact part number and required quantity before ordering.
Shop EPX2155 Suction Set PartsTitan EPX2155 Suction Set Assembly FAQ
What does the EPX2155 suction set assembly do?
The suction set provides the material-intake path used to draw coating from the supply container toward the piston pump.
What is the part number for this EPX2155 suction set assembly?
This parts category is identified for the Titan EPX2155 Suction Set Assembly referenced as P/N 0551104. Verify the applicable machine and parts diagram before ordering individual components.
Can a suction set problem prevent the EPX2155 from priming?
Yes. A restricted intake path, clogged strainer, loose connection or unwanted air entering the suction side can interfere with material intake and make priming difficult.
What should I inspect if the EPX2155 will not draw paint?
Check the material supply, inlet strainer, suction tube or hose, fittings, sealing components and pump inlet. If the intake path is clear and sealed, continue diagnosis at the piston pump.
Can a suction-side air leak cause unstable spray pressure?
Air entering the material-intake path can interfere with consistent pump supply and may contribute to irregular material delivery or unstable operation.
Are EPX2155 suction parts interchangeable with other EPX models?
Do not assume interchangeability. Compare the applicable model-specific diagrams and exact replacement part numbers before using a suction component listed for another EPX sprayer.
What should I verify before ordering EPX2155 suction set parts?
Confirm the EPX2155 model, P/N 0551104 where applicable, correct Suction Set Assembly diagram, numbered callout, component description, exact replacement part number and required quantity.
Need Help Finding an EPX2155 Suction Set Part?
Have your EPX2155 model information, P/N 0551104 reference, serial number when available, existing part number and exploded-diagram callout ready to help identify the correct suction, strainer, fitting, connector, sealing or related material-intake component.
