Shop Titan 440xc Filter Block Assembly Parts
Find genuine Titan 440xc filter block assembly service parts for your airless sprayer. Browse the filter housing, filter element, seals, gaskets and bypass valve components, then match the exact OEM number to the repair your inspection identifies.
Find 440xc Filter and Valve Service Components
Select the part required for your installed filter block configuration. The housing, filter element and valve assembly are separate listings, so check package contents before completing your order.
Locate the filter housing at diagram position 1. Inspect the housing, threads and sealing surfaces when assessing a leak or damaged enclosure.
View 0532360A Filter Housing →Find the 500-200-03 coarse filter at position 2. Verify that the listed mesh is appropriate for your coating and spray setup.
Shop 500-200-03 Filter Elements →Locate the valve assembly at position 29. Review the supplied components before ordering separate handles, pins or seals.
Explore 700-258 PrimeSpray Valve →How to Choose the Correct 440xc Filter Block Part
Confirm your equipment identification and installed assembly before selecting parts. Similar-looking gaskets and O-rings can differ in material or dimensions, and a shared diagram position does not establish interchangeability.
Confirm the Titan 440xc model, serial number and filter block configuration.
Identify whether the affected item is the filter, housing, seal or valve component.
Verify the exact part number and any applicable replacement reference.
Check mesh, seal material, supplied quantity and package contents.
| Diagram Position | Titan OEM Reference | Component | Ordering Check |
|---|---|---|---|
| 1 | 0532360A | Filter housing | Confirm contents and configuration |
| 2 | 500-200-03 | Green 30 mesh coarse filter | 2-pack; verify mesh selection |
| 5 / 6 | 221-012 / 222-012 | Viton / PTFE O-rings | Match material and seal location |
| 7 | 800-924 | Bypass housing | Inspect mating parts |
| 8 | 700-721 / 700-897 | O-ring listings | Confirm applicable seal |
| 14 | 700-697 | Valve handle | Check associated control hardware |
| 23 | 0509585 | Transducer gasket | Replaces 700-804 |
| 29 | 700-258 | PrimeSpray valve assembly | Confirm supplied components |
Inspect the Filter Block Before Replacing Parts
A filter element traps debris, while the housing contains the element. Assess both during maintenance and use model-specific troubleshooting to identify restrictions, damaged seals or valve faults.
Inspect the filter element and relevant fluid path for buildup. Follow the specified cleaning or replacement procedure.
Locate the leak and inspect the correct seal, mating surface and housing threads before choosing a replacement.
Check the coating condition and filtration throughout the system. A new housing alone does not replace a damaged filter element.
Inspect the relevant handle, cam and valve components using the service procedure. Diagnose the fault before ordering an assembly.
Service safety: Disconnect power, relieve system pressure and follow the Titan maintenance instructions before opening the filter housing or removing valve components. Never check pressurized leaks with your hand.
Titan 440xc Filter Block Assembly FAQ
Review these fitment, filtration and ordering questions before selecting replacement components.
Have your model, serial number, diagram position and existing OEM number available for help confirming the correct component and package contents.
Call 713-931-0006 for Fitment Help
