Admiral Series Overview
Titan designed the Admiral for professional coating work requiring pneumatic power, serviceable Severe Service fluid sections and multiple mounting choices. The documented platform supports architectural coatings, industrial maintenance, corrosion control, waterproofing, roofing and marine protective coating applications, including low-VOC, high-solids and abrasive materials when equipment and accessories are correctly selected.
| Verified model | Documented configuration |
|---|---|
| 830-451 | Portable, 30:1 |
| 941-421 | Portable, 40:1 |
| 941-441 | Portable, 40:1 |
| 860-451 | Portable, 60:1 |
| 860-461 | Portable, 60:1 |
| 830-331 | Wall mount, 30:1 |
| 941-183 | Drum mount, 40:1 |
| 941-331 | Wall mount, 40:1 |
| 941-431 | Wall mount, 40:1 |
| 860-355 | Wall mount, 60:1 |
Core Systems Supported
Pneumatic Drive
850-555 and 850-557 air motors convert regulated compressed air into reciprocating pump motion.
Severe Service Fluid Delivery
The 155-559, 181-556, 185-551 and 245-556 fluid sections generate coating pressure according to the assigned ratio and model.
Air Preparation and Control
The 928-835 airline assembly supports shutoff, lubrication, regulation, pressure indication and moisture separation.
Material Intake and Filtration
Model-specific siphon assemblies and 920-series outlet filters support clean, stable coating flow.
Professional Service Applications
Use this hub for complete-model identification, air-motor service, fluid-pump rebuilding, filter maintenance, siphon diagnosis, pressure-relief repair, cart or stationary mounting service, accessory planning and restoration of material flow or spray pressure on documented Admiral systems.
Major Admiral Assemblies
These cards link only to confirmed Admiral assembly categories documented on the live machine-family page.
Verified Admiral system
View Admiral Air MotorsTitan 850-555 / 850-557 Admiral Air Motors
Convert regulated compressed air into reciprocating motion for the connected fluid pump.
Verified Admiral system
View Fluid Pump AssemblyTitan 155-559 Fluid Pump Assembly
Documented fluid section used in selected 60:1 Admiral configurations.
Verified Admiral system
View Fluid Pump AssemblyTitan 181-556 Fluid Pump Assembly
Documented 40:1 fluid section used in a wall-mount Admiral configuration.
Verified Admiral system
View Fluid Pump AssemblyTitan 185-551 Fluid Pump Assembly
Documented 40:1 fluid section used in portable, wall-mount and drum-mount arrangements.
Verified Admiral system
View Fluid Pump AssemblyTitan 245-556 Fluid Pump Assembly
Documented 30:1 fluid section used with the 850-557 air motor.
Verified Admiral system
View Airline AssemblyTitan 928-835 Airline Assembly
Provides shutoff, lubrication, regulation, pressure indication and moisture separation for the air motor.
Admiral Parts Buying Guide
1. Confirm the complete model
Use the full model number because pressure ratio and mounting style do not identify every component.
2. Identify the assembly
Match the motor, pump, air assembly, outlet, filter, bleed, siphon or mounting diagram.
3. Diagnose the operating symptom
Inspect connected systems because pressure, priming and cycling complaints can share multiple causes.
4. Match the diagram item
Use the documented assembly number, item callout and current product listing before ordering.
Admiral Maintenance
Follow Titan’s pressure-relief procedure before service. Inspect grounded high-pressure hoses before each use, maintain clean moisture-free air, service the lubricator correctly, clean model-specific siphon and outlet filters, flush with compatible materials at the lowest practical pressure, and record recurring packing, valve or sealing wear.
Repair Planning
Record the complete Admiral model, 30:1, 40:1 or 60:1 ratio, portable/wall/drum configuration, installed air motor, fluid pump, filter, siphon and bleed assemblies, coating type and exact symptom. Photograph the installed configuration and confirm related components before choosing individual service parts or complete assemblies.
Fast Navigation
Admiral Portable Models PartsAdmiral Wall Mount and Drum Mount Models PartsAdmiral 850-555 and 850-557 Air Motor PartsAdmiral 155-559 Fluid Pump Assembly PartsAdmiral 181-556 Fluid Pump Assembly PartsAdmiral 185-551 Fluid Pump Assembly PartsAdmiral 245-556 Fluid Pump Assembly PartsAdmiral 928-835 Air Assembly PartsAdmiral Heavy Duty Cart PartsAdmiral Pump Mount Drum Cover PartsAdmiral Pump Mounts PartsAdmiral Wall Bracket 590-300 Parts
SPEEFLO Admiral FAQs
What type of page is the SPEEFLO Admiral page?
It is a machine-family replacement-parts hub for portable, wall-mount and drum-mount Admiral air-powered airless sprayers.
Which Admiral models are verified in Titan documentation?
The documented family includes portable models 830-451, 941-421, 941-441, 860-451 and 860-461, plus stationary models 830-331, 941-183, 941-331, 941-431 and 860-355.
Which pressure ratios are used in the Admiral family?
Titan documents 30:1, 40:1 and 60:1 Admiral configurations.
Which air motors are used?
Titan documents Admiral air motors 850-555 and 850-557.
Which fluid pumps are used in the Admiral family?
The documented fluid-pump families are 155-559, 181-556, 185-551 and 245-556.
What is the function of the 928-835 air assembly?
It supplies the air-motor control and preparation group, including shutoff, lubrication, regulation, pressure indication and moisture separation.
Which cart supports portable Admiral models?
Titan documents heavy-duty cart assembly 590-301 for portable Admiral configurations.
Which mounting components support stationary models?
Titan documents drum cover 219-600, wall bracket 590-300, adapter plate 219-504 and mounting kits 219-100 or 219-200 where assigned.
Which outlet filters are documented?
Titan documents 920-554, 920-556 and 920-605 filter assemblies in model-specific configurations.
Which siphon assemblies are documented?
Portable configurations use 103-807 or 103-810; stationary configurations use 103-806 or 103-808 according to model.
How should low pressure be diagnosed?
Inspect compressor capacity, air regulation, filter condition, spray-tip wear, hose size, siphon integrity and the assigned fluid pump before replacing major components.
Why must the complete Admiral model be confirmed?
Different Admiral models use different air motors, fluid pumps, outlets, filters, siphon assemblies and mounting arrangements.
Find the Correct Admiral Parts Diagram
Start with the complete machine model and installed assembly. This prevents mismatching 30:1, 40:1 and 60:1 components or ordering a portable part for a wall-mount or drum-mount system.
Search using:
- Complete SPEEFLO Admiral model number
- Pressure ratio and mounting style
- Assembly name, item number or Titan part number
- Operating symptom or component name
