PowrCoat 745 Gun Manifold Assemblies Parts

PowrCoat 745 Gun Manifold Assemblies Parts
Titan 814-002 Nipple
Titan 814-002 Nipple

Item No: 1

Part #: 814-002

  OEM Titan Fluid System Component Titan 814-002 Nipple is an OEM hex nipple that connects ...

$25.10
QTY:
Titan 814-004 Nipple
Titan 814-004 Nipple

Item No: 1A

Part #: 814-004

  OEM Titan Fluid System Component Titan 814-004 Nipple is an OEM 3/8" M x 3/8" M hex nippl...

$19.00
QTY:
Titan 941-555 Ball Valve
Titan 941-555 Ball Valve

Item No: 2A

Part #: 941-555

  OEM Titan Fluid Control Component Titan 941-555 Ball Valve is an OEM flow control compone...

Retail Price: $157.90
You save: $19.74 (12.50%)
Our Price: $138.16
QTY:
Titan 227-006 Outlet Fitting
Titan 227-006 Outlet Fitting

Item No: 3

Part #: 227-006

  OEM Titan Fluid System Component Titan 227-006 Outlet Fitting is an OEM component that co...

$18.50
QTY:
Titan 808-555 Fitting
Titan 808-555 Fitting

Item No: 3A

Part #: 808-555

  OEM Titan Fluid Component Titan 808-555 Fitting is an OEM NPT-to-NPS fitting used to conn...

Retail Price: $43.00
You save: $3.27 (7.60%)
Our Price: $39.73
QTY:
Titan 227-033 Pipe Plug
Titan 227-033 Pipe Plug

Item No: 4

Part #: 227-033

  OEM Titan Sealing Component Titan 227-033 Pipe Plug is an OEM sealing component that clos...

$5.40
QTY:
Titan 970-100 Manifold Block, 3/8
Titan 970-100 Manifold Block, 3/8

Item No: 5

Part #: 970-100

  OEM Titan Fluid Distribution Component Titan 970-100 Manifold Block, 3/8 is an OEM fluid ...

Retail Price: $180.30
You save: $22.54 (12.50%)
Our Price: $157.76
QTY:
Titan 814-004 Nipple
Titan 814-004 Nipple

Item No: 6

Part #: 814-004

  OEM Titan Fluid System Component Titan 814-004 Nipple is an OEM 3/8" M x 3/8" M hex nippl...

$19.00
QTY:



Optional Multi-Gun Distribution Components · 1/4-Inch and 3/8-Inch Configurations

Build and Service PowrCoat 745 Gun Manifold Assemblies

Shop verified parts for PowrCoat 745 Gun Manifold Assemblies, including reducing and straight nipples, individual ball valves, outlet fittings, pipe plugs, and the 3/8-inch manifold block. Titan documents optional 2-, 3-, and 4-gun assemblies in 1/4-inch and 3/8-inch versions, so technicians should match the exact manifold size and branch position before ordering.

01
Verified Multi-Gun Diagram
Titan documents 2-, 3-, and 4-gun manifold configurations.
02
Two Connection Sizes
Official assemblies are available in 1/4-inch and 3/8-inch layouts.
03
Branch-by-Branch Control
Ball valves allow individual gun outlets to be isolated.
04
Confirmed Product Links
Only genuine parts listed on the supplied page are featured.
Assembly Overview

How PowrCoat Multi-Gun Manifolds Divide Pressurized Coating

This page is an exploded optional-accessory and replacement-parts category for PowrCoat multi-gun manifold assemblies. Titan’s manual identifies 975-212, 975-213, and 975-214 as 1/4-inch 2-, 3-, and 4-gun assemblies and 975-312, 975-313, and 975-314 as their 3/8-inch counterparts.

The inlet fitting connects the sprayer’s pressurized fluid supply to the manifold block. Each branch uses a nipple, shutoff valve, and outlet fitting so coating can be routed to multiple hoses and guns while unused ports remain securely plugged.

Main Functions

Functions Supported by the Gun Manifold Assemblies

  • Divides one coating supply into multiple gun branches.
  • Allows individual outlets to be opened or isolated.
  • Supports 2-, 3-, and 4-gun production layouts.
  • Connects high-pressure hoses through dedicated outlet fittings.
  • Seals unused threaded ports with the specified pipe plug.
Service Applications

When Contractors Use This Manifold Parts Diagram

  • Adding or restoring multiple spray-gun outlets.
  • Correcting leakage at a nipple, fitting, plug, or valve.
  • Replacing a damaged branch shutoff valve.
  • Repairing stripped or damaged manifold-block ports.
  • Reconfiguring a 1/4-inch or 3/8-inch gun setup.
Troubleshooting

PowrCoat 745 Gun-Manifold Symptoms and Diagnostic Priorities

Relieve system pressure before touching any branch. Diagnose hose, gun, tip, coating, valve position, and connection integrity before replacing manifold components.

Operating symptom Inspection points Recommended action
One gun branch has weak or no flow 941-555 valve position, branch nipple, outlet fitting, hose, gun filter, tip, and coating restriction Compare the affected branch with a working branch and isolate the restriction before replacing the valve or fitting.
Fluid leaks at a branch connection 814-002 or 814-004 nipple, 227-006 or 808-555 fitting, thread condition, sealant, alignment, and manifold port Locate the exact threaded interface and inspect both mating threads before replacement.
Closed outlet still passes coating 941-555 valve handle position, internal valve sealing, contamination, branch pressure, and downstream hose condition Confirm complete closure and flush contamination before replacing the ball valve.
Unused port leaks 227-033 plug, port threads, compatible sealant, plug depth, cracks, and cross-threading Depressurize, remove, inspect, and reseal the plug before replacing it or the manifold block.
Flow differs between guns hose length, tip size, gun filter, valve opening, coating viscosity, manifold restriction, and outlet fittings Standardize the downstream setup and compare branch pressure before replacing manifold parts.
Manifold block will not seal after fitting replacement 970-100 port threads, fitting thread type, cross-threading, overtightening, cracks, and damaged sealing surfaces Verify the correct fitting and inspect the block port before deciding that the manifold block requires replacement.
Verified Replacement Components

High-Value PowrCoat 745 Gun-Manifold Parts

Only genuine parts listed on the supplied category and confirmed in Titan’s manifold documentation are included.

Reducing Hex Nipple

Titan 814-002 Nipple

Verified item 1 connection used between manifold and valve components where a 3/8-inch male to 1/4-inch male transition is required.

View Titan 814-002
Straight Hex Nipple

Titan 814-004 Nipple

Verified 3/8-inch male-to-male nipple used at documented manifold connection positions in compatible PowrCoat multi-gun layouts.

View Titan 814-004
Gun-Outlet Shutoff Valve

Titan 941-555 Ball Valve

Verified fluid-control valve used to isolate an individual gun outlet during multi-gun spraying, setup, flushing, or service.

View Titan 941-555
Outlet Connection

Titan 227-006 Outlet Fitting

Verified hex outlet fitting that connects the manifold flow path to the attached high-pressure hose or downstream gun circuit.

View Titan 227-006
Alternate Hex Fitting

Titan 808-555 Fitting

Verified fitting listed for the alternate manifold configuration and used to adapt the documented outlet connection.

View Titan 808-555
Unused-Port Closure

Titan 227-033 Pipe Plug

Verified pipe plug used to close an unused threaded manifold port and preserve a sealed high-pressure fluid circuit.

View Titan 227-033
Three-Eighth-Inch Manifold Block

Titan 970-100 Manifold Block, 3/8

Verified distribution block that divides pressurized coating among multiple 3/8-inch gun-outlet branches.

View Titan 970-100
Buying Guide

How to Select the Correct Gun-Manifold Component

STEP 1

Confirm manifold size

Identify the 1/4-inch or 3/8-inch assembly before selecting fittings.

STEP 2

Count gun branches

Titan documents 2-, 3-, and 4-gun complete assemblies.

STEP 3

Match the exact position

Different positions use reducing nipples, straight nipples, fittings, valves, or plugs.

STEP 4

Inspect mating threads

A new fitting will not seal a cracked or cross-threaded manifold port.

Maintenance

Maintenance Practices for Reliable Multi-Gun Distribution

  • Flush every active branch before coating dries.
  • Exercise each ball valve through full open and closed positions.
  • Inspect nipples, fittings, plugs, and ports for leakage or thread damage.
  • Keep hose, gun-filter, and tip configurations appropriate for balanced output.
  • Support connected hoses so excessive leverage does not load the manifold.
  • Relieve all pressure before changing any branch component.
Repair Planning

Plan a Complete PowrCoat 745 Gun-Manifold Repair

For a single weak branch, compare the valve, nipple, fitting, hose, gun filter, and tip against a working branch. For leakage, identify the precise joint and inspect both mating threads, sealant condition, alignment, and manifold-port integrity.

For manifold reconfiguration, verify the required gun count and whether the setup uses the 1/4-inch or 3/8-inch family. Do not mix fittings or assume that visually similar nipples share the same thread dimensions.

Fast Navigation

Shop Major PowrCoat 745 Gun-Manifold Components

FAQ Section

PowrCoat 745 Gun Manifold Assembly FAQs

Verified answers covering assembly types, gun count, connection sizes, branch control, leakage diagnosis, flow balance, component selection, and safe service.

What type of page is the PowrCoat 745 gun-manifold page?+
It is an exploded replacement-parts category for optional multi-gun manifold assemblies used with PowrCoat equipment.
Which manifold configurations does Titan document?+
Titan documents 2-, 3-, and 4-gun assemblies in both 1/4-inch and 3/8-inch versions.
Which complete manifold assembly numbers are documented?+
Titan lists 975-212, 975-213, and 975-214 for 1/4-inch assemblies and 975-312, 975-313, and 975-314 for 3/8-inch assemblies.
What does the manifold block do?+
The manifold block divides one pressurized coating supply into multiple controlled outlet branches for separate spray guns.
Why are ball valves used on a multi-gun manifold?+
They allow individual outlets to be opened or isolated without disturbing the remaining manifold branches.
What is the difference between 814-002 and 814-004?+
814-002 is documented as a reducing connection, while 814-004 is a straight 3/8-inch male-to-male nipple. Match the diagram position and thread size.
Why is a pipe plug installed?+
The 227-033 plug closes an unused threaded port so coating cannot escape and pressure remains contained.
What causes one gun branch to have weak flow?+
Inspect the branch ball valve, nipple, outlet fitting, hose, gun filter, tip, and coating restriction before replacing manifold parts.
What causes leakage at a manifold joint?+
Possible causes include loose fittings, damaged threads, incorrect sealant, cracked fittings, a damaged manifold port, or an improperly seated pipe plug.
Should all manifold outlets use the same hose and tip setup?+
Balanced hose length, gun condition, and tip sizing help produce more consistent flow, but the correct configuration depends on the coating and application.
Can one outlet be serviced while others remain installed?+
Yes, but the entire system must first be shut down and fully depressurized. Do not rely only on closing an individual ball valve.
What safety procedure is required before manifold service?+
Lock each gun, shut off the air supply, open the pressure-relief path, trigger grounded guns into a metal container, and verify zero pressure before loosening fittings.
Find the Correct Replacement Part

Restore Balanced Multi-Gun Flow and Leak-Free Branch Control

Browse verified PowrCoat 745 manifold nipples, shutoff valves, outlet fittings, plugs, and distribution-block components.

Search using:
  • Titan part number
  • 1/4-inch or 3/8-inch manifold
  • 2-, 3-, or 4-gun configuration
  • Nipple, valve, fitting, plug, or block
  • Leakage, restriction, imbalance, or shutoff symptom

Related PowrCoat 745 Gun-Manifold Searches
