Genuine Titan OEM | Rigid Suction System Parts
Shop Titan Elite 3000 Rigid Suction Set Parts
Maintain reliable coating intake and efficient pump priming with Titan Elite 3000 Rigid Suction Set Parts from AllTitanParts. Shop genuine Titan OEM suction system assemblies, suction hoses, return hoses and inlet suction filters for your Elite 3000 high-pressure airless paint sprayer. Use the factory exploded diagram to identify the correct replacement part and restore dependable fluid delivery from the coating container to the pumping system.
Rigid Suction Set Overview
Buy Genuine Titan Elite 3000 Rigid Suction System Parts
The Titan Elite 3000 Rigid Suction Set is part of the airless sprayer's material intake and return system. It supports the movement of coating material from the supply container toward the pump while providing a return pathway during applicable priming and circulation procedures.
A properly functioning suction system helps the pump receive a consistent supply of coating material. The suction hose assembly provides the intake connection, the suction filter helps prevent larger debris from entering the pumping mechanism, and the return hose carries material through the return circuit.
Damaged hoses, loose connections, accumulated coating residue and restricted filters can affect material intake. These conditions may contribute to difficult priming, intermittent fluid flow, air ingestion, cavitation and reduced spraying performance.
This category features 4 individually listed Titan OEM replacement products: Titan 2405950 Suction System Assembly, Titan 2405951 Suction Hose Assembly, Titan 2390606 Return Hose Assembly and Titan 2323325 Suction Filter.
Whether you are replacing an individual suction component or servicing the complete intake system, AllTitanParts helps you identify the correct OEM part number using the factory exploded diagram.
OEM Parts Directory
Titan Elite 3000 Rigid Suction Set Parts List
Use the following parts directory with the factory exploded diagram to locate the correct replacement component before purchasing.
| Diagram Ref. | Titan Part Number | Part Description | Primary Function |
|---|---|---|---|
| Not specified | 2405950 | Suction System Assembly | Provides a packaged suction system assembly for the specified Elite 3000 configuration. |
| 1 | 2405951 | Suction Hose Assembly | Transfers coating material from the supply container toward the pump inlet. |
| 2 | 2390606 | Return Hose Assembly | Provides the return pathway for coating material during applicable circulation operations. |
| 3 | 2323325 | Suction Filter | Strains larger debris and particles from coating material entering the suction system. |
These are the four individually listed OEM products in the category, not necessarily every physical component included in the complete suction system. Verify assembly contents and quantities on the product listing.
Featured OEM Suction Components
Shop Titan Elite 3000 Suction Assemblies, Hoses and Filters
Titan 2405950 Suction System Assembly
The Titan 2405950 Suction System Assembly is a genuine OEM replacement assembly listed for the Elite 3000 rigid suction configuration.
The suction system supplies coating material from the container to the pump. Maintaining an unobstructed intake pathway helps support consistent pump priming and fluid delivery.
Consider complete assembly replacement when inspection identifies multiple damaged suction components or when the manufacturer's service procedure specifies replacement of the assembly.
Confirm the included components and exact equipment fitment before ordering.
OEM Part Number: 2405950Titan 2405951 Suction Hose Assembly
The Titan 2405951 Suction Hose Assembly provides the specified intake connection for transferring coating material from the supply container toward the Elite 3000 pump.
Damage to the hose or its connections can interfere with proper material intake. Cracks, restrictions, deformation or leaking fittings may cause the pump to draw air or lose prime.
Inspect the hose assembly for physical damage and accumulated coating residue. Replace it when inspection confirms defects that prevent reliable operation.
OEM Part Number: 2405951 | Ref. 1Titan 2390606 Return Hose Assembly
The Titan 2390606 Return Hose Assembly is an OEM fluid return component used with the Elite 3000 suction system.
During applicable priming, flushing and circulation procedures, the return hose provides a controlled pathway for coating material to move back toward the supply container.
Inspect the hose for cracks, restrictions, abrasion and damaged connections. A defective return hose can cause leakage or interfere with normal fluid circulation.
OEM Part Number: 2390606 | Ref. 2Titan 2323325 Suction Filter
The Titan 2323325 Suction Filter is a genuine OEM filtration component for the Elite 3000 suction system.
The filter helps prevent larger particles, dried coating fragments and debris from entering the pump. Maintaining a clean filter supports consistent fluid intake and reduces the likelihood of suction restrictions.
Inspect the filter for blockage, damage and excessive contamination. Clean it according to Titan's instructions or replace it when necessary.
OEM Part Number: 2323325 | Ref. 3Suction System Operation
How the Titan Elite 3000 Rigid Suction Set Works
Coating Intake
The suction assembly provides a pathway for coating material to enter the sprayer from the supply container.
Material Filtration
The suction filter strains larger particles and debris before material reaches the pump inlet.
Pump Supply
The intake hose and connections support continuous material delivery to the pumping mechanism.
Return Circulation
The return hose provides a pathway for material circulation during applicable priming and flushing procedures.
Troubleshooting and Repair
Common Titan Elite 3000 Rigid Suction Set Problems
Poor material intake can have several causes. Inspect the suction assembly and related pump components according to Titan's service instructions before replacing parts.
| Observed Problem | Components to Inspect | Recommended Check |
|---|---|---|
| Sprayer will not prime | 2405951 Suction Hose and 2323325 Filter | Check material supply, suction restrictions, hose connections and filter blockage. |
| Pump repeatedly loses prime | 2405951 Suction Hose Assembly | Inspect for air leaks, cracks, damaged fittings and inadequate suction immersion. |
| Reduced coating intake | 2323325 Suction Filter and intake hose | Inspect for dried coating, clogged filtration and hose restrictions. |
| Material leaks from return line | 2390606 Return Hose Assembly | Check the return hose and fittings for cracks, wear or improper connections. |
| Irregular fluid delivery | 2405951 Suction Hose and 2323325 Filter | Inspect for air ingestion, intake restrictions and inconsistent material supply. |
| Repeated filter blockage | 2323325 Suction Filter | Inspect coating cleanliness and filter condition. Remove accumulated debris. |
| Multiple suction components damaged | 2405950 Suction System Assembly | Evaluate whether a complete assembly replacement is more appropriate than individual repairs. |
OEM Part Number Identification
Titan Elite 3000 Rigid Suction Replacement Part Numbers
Use these manufacturer part numbers when identifying the correct rigid suction set components:
- Titan 2405950: Suction System Assembly.
- Titan 2405951: Suction Hose Assembly, diagram reference 1.
- Titan 2390606: Return Hose Assembly, diagram reference 2.
- Titan 2323325: Suction Filter, diagram reference 3.
The rigid suction configuration uses Titan 2405950 as its listed complete suction system assembly and Titan 2405951 as its listed suction hose assembly.
The separately listed flexible suction configuration uses different suction system and suction hose part numbers. However, Titan 2390606 Return Hose Assembly and Titan 2323325 Suction Filter are listed in both categories.
Verify the complete equipment configuration before substituting any parts between the rigid and flexible suction systems. Shared part listings do not establish interchangeability for other components.
OEM Buying Guide
How to Order the Correct Titan Elite 3000 Rigid Suction Part
Confirm Your Sprayer
Verify the Titan Elite 3000 model, serial number and rigid suction system configuration.
Locate the Component
Identify the suction assembly, intake hose, return hose or filter using the factory exploded diagram.
Match the OEM Number
Compare the exact Titan part number and diagram reference with the product listing.
Purchase the Replacement
Confirm fitment and assembly contents, then order the correct OEM replacement through AllTitanParts.
Preventive Maintenance
Maintain Your Titan Elite 3000 Rigid Suction System
Clean the Suction Filter
Inspect the suction filter for coating residue and debris. Clean it according to Titan's instructions and replace damaged filtration components.
Inspect Suction Connections
Check intake connections and sealing surfaces for damage that could allow air into the suction system.
Check Hose Condition
Inspect suction and return hoses for cracks, abrasion, deformation and restrictions that could affect fluid movement.
Flush the Fluid System
Follow the manufacturer-recommended flushing procedure to reduce dried coating buildup inside the suction and return circuits.
Prevent Container Contamination
Keep supply containers clean and prevent large particles or foreign objects from entering the intake system.
Follow Storage Procedures
Use Titan-approved cleaning and storage practices to protect suction components between painting jobs.
Related Titan Elite 3000 Assemblies
Shop More Titan Elite 3000 Airless Sprayer Parts
Elite 3000 Main Assembly
Browse main assembly components and replacement parts for the Elite 3000 sprayer.
Elite 3000 Pump Assembly
Explore pump components and related service parts for fluid delivery repairs.
Elite 3000 Flexible Suction Set
Browse the separately listed flexible suction configuration and its replacement components.
Elite 3000 Outlet Valve Assembly
Find outlet valve components used in the Elite 3000 pumping system.
Elite 3000 High Pressure Filter
Shop high-pressure filtration components for the downstream fluid system.
Elite 3000 Accessories
Explore additional sprayer accessories and compatible service components.
Titan Elite 3000 Rigid Suction Set Repair Safety
Before servicing the rigid suction system, switch off the sprayer, disconnect electrical power and follow Titan's complete pressure-relief procedure. Never disconnect fluid fittings while the system is pressurized or attempt to stop a leak with your hand. High-pressure fluid injection injuries require immediate emergency medical attention. Follow the applicable Titan service manual for suction assembly removal, filter maintenance, component installation, priming and leak testing.
Genuine Titan Elite 3000 Rigid Suction Parts
Order Titan Elite 3000 Rigid Suction Set Parts Today
Shop genuine Titan OEM suction system assemblies, suction hoses, return hoses and inlet filters. Find Titan 2405950, 2405951, 2390606 and 2323325 using the factory exploded parts diagram.
Shop Elite 3000 Rigid Suction PartsFrequently Asked Questions
Titan Elite 3000 Rigid Suction Set FAQ
What is the Titan Elite 3000 Rigid Suction Set?
It is a suction system configuration for the Titan Elite 3000 airless sprayer. It includes components associated with coating material intake, filtration and return circulation.
How many replacement parts are listed in this category?
AllTitanParts lists four individual genuine Titan OEM products in the Elite 3000 Rigid Suction Set Parts category.
What is the Titan Elite 3000 rigid suction system assembly part number?
Titan 2405950 is the Suction System Assembly listed for the Elite 3000 rigid suction configuration.
What is the Titan Elite 3000 rigid suction hose part number?
Titan 2405951 is the Suction Hose Assembly listed at diagram reference 1.
What is the Titan Elite 3000 return hose part number?
Titan 2390606 is the Return Hose Assembly listed at diagram reference 2.
What is the Titan Elite 3000 suction filter part number?
Titan 2323325 is the Suction Filter listed at diagram reference 3.
What is the difference between the Elite 3000 rigid and flexible suction sets?
The two configurations have separately listed suction system and suction hose assemblies. The rigid configuration lists Titan 2405950 and 2405951, while the flexible configuration lists different suction system components. Verify the configuration before ordering.
Do the rigid and flexible suction sets use the same return hose?
Both AllTitanParts categories list Titan 2390606 Return Hose Assembly. Confirm the correct equipment configuration and part number before installation.
Do the rigid and flexible suction sets use the same suction filter?
Both categories list Titan 2323325 Suction Filter. Verify the applicable model and parts diagram before ordering.
Why is my Titan Elite 3000 not priming properly?
Possible causes include clogged suction filtration, damaged suction hoses, loose connections, trapped air, insufficient coating material or pump inlet valve problems. Inspect the intake system and related pump components.
Should I replace the complete suction system or individual parts?
Choose based on the diagnosed problem and component condition. Individual hoses and filters can be replaced separately, while complete assembly replacement may be appropriate when multiple components are damaged. Confirm assembly contents before ordering.
Where can I buy Titan Elite 3000 Rigid Suction Set Parts?
Shop Titan Elite 3000 Rigid Suction Set Parts at AllTitanParts. For assistance identifying the correct OEM component, call 713-931-0006.
Titan OEM Parts Assistance
Need Help Finding Elite 3000 Rigid Suction Parts?
Have your Titan Elite 3000 model, serial number, suction configuration, diagram reference and existing part number ready when requesting replacement part assistance.
