The first split is the air supply. The AirCoat 423 and 620 are air-powered and work with a compressor. The AirCoat AAA and the MultiFinish 440 are electric with an onboard compressor. The 620 delivers the most here at 1.25 GPM, the MultiFinish has the highest pressure at 3300 psi, and the AAA has the lowest delivery at 0.35 GPM.
The four systems
All four are air-assisted airless sprayers: a small amount of air is added to the fluid pressure, which allows a lower fluid pressure than plain airless. Titan says the lower pressure gives greater control of spray, and describes the result as fine atomization and smooth, bubble-free finishes. They differ in what drives the pump and where the air comes from.
Titan air-assisted systems compared
| Spec | MultiFinish 440 | AirCoat AAA | AirCoat 620 | AirCoat 423 |
|---|---|---|---|---|
| Drive | Electric | Electric | Air-powered, 6 in. air motor | Air-powered, 4 in. air motor |
| Air supply | Onboard compressor | Onboard compressor | Works with an air compressor | Works with an air compressor |
| Max fluid pressure | 3300 psi | 2800 psi | 2320 psi | 2670 psi |
| Ratio | not listed | not listed | 20:1 | 23:1 |
| Delivery | 0.58 GPM | 0.35 GPM | 1.25 GPM | 0.50 GPM |
Figures are Titan's, as reproduced on dealer pages. We leave out the air-pressure setting of the MultiFinish because the published figures do not agree. The AAA lists 35 psi of air.
Electric with compressor, or air-powered
This is the choice that decides the rest. The AirCoat 423 and 620 have an air motor that drives the pump, so they need a compressor on site; Titan lists their features as dual regulators, an air filter, an air lubricator, a fluid pressure gauge and two air pressure gauges. The AirCoat AAA and the MultiFinish 440 bring their own compressor and plug in, so a shop with no air line, or a crew that moves between sites, runs them without a separate compressor.
The reverse also holds: a shop that already has a compressor on site can power a 423 or 620 from it. We do not give a minimum compressor size, because we found no figure for these two from Titan. Check your manual, or call (713) 931-0006 before you buy one.
Pressure and delivery
Read the table by what you spray. The 620 has the highest delivery here at 1.25 GPM, but the lowest pressure, 2320 psi, and its ratio is 20:1. The 423 has a smaller 4 in. motor at 23:1 for 2670 psi and 0.50 GPM. The MultiFinish 440 has the highest pressure of the four at 3300 psi and 0.58 GPM, and the AAA sits at 0.35 GPM and 2800 psi, the lowest delivery.
Titan lists the AirCoat 423 and 620 for solvent and water-based paints, primers, varnishes, polyurethanes, stains and lacquers, slow-setting 2K materials and UV hardening paints, on cabinets, furniture, doors, trim and small metal finishing, in small to medium wood and metal finishing shops. For the AAA, Titan's wording is high production fine finishing, interior and exterior. We have no basis to say which fits a given coating better, so check the coating maker's data sheet.
What comes in the box
- AirCoat AAA complete (0508074A): a GM 3600 AA gun, a Brilliant 9/20 tip, a 1/4 in. by 50 ft bonded hose, and 5 ft fluid and air whips. The 0550039 is the bare unit, 120V.
- AirCoat 423 and 620 complete: a Titan 3600 AA gun with a flat tip, a 50 ft air hose and a fluid hose. They are offered as cart or spider mounts, bare or complete, so check the listing to see which one you are buying.
- MultiFinish 440: dealer pages list a GM 3600 AA gun with it.
Titan's gun is a replaceable part. The site lists the GM 3600 AirCoat gun with flat tip guard and a complete gun, 50 ft hose and flat tip kit. We do not explain what the AA in the gun name stands for.
Where each one's parts are
Parts by system
| System | Where to look | Examples |
|---|---|---|
| AirCoat 620 | 620 fluid pump, 620 filter, lubricator, regulator | 0533425 leather V-packing, 0533426 PTFE V-packing, 0533569 filter element |
| AirCoat 423 | 423 fluid pump, 423 filter, lubricator, regulator | 0533420 and 0533403 leather V-packings, 0533557 filter element, 51519 inlet ball |
| AirCoat AAA | Air-Assisted main assembly and spray system hub | 0551376 compressor filter, 0508609A compressor, 0278240 diaphragm |
| MultiFinish 440 | MultiFinish 440 diagrams in the fine-finishing section | Compressor, drive and fluid section assemblies |
The AirCoat 423 and 620 each have their own fluid pump page with different numbers, so use the page for your model. The parts hub is Spraytech AirCoat Sprayer Parts.
The 423 and 620 do share some parts, for example the 0533514 high-pressure filter element and the 0533517 bleed valve assembly. Their air filters do not: the 620 uses 0533569 and the 423 uses 0533557.
Choosing
- No compressor on site, and you move around: look at the electric pair, the AAA or the MultiFinish.
- You already run a compressor and want the most delivery of the four: the 620, at 1.25 GPM.
- Lower delivery on an air supply: the 423, at 0.50 GPM and a higher pressure than the 620.
- You want the highest pressure of the four on electric power: the MultiFinish 440, at 3300 psi.
These are comparisons of Titan's printed figures, not a ranking, and parts support differs too. If you are replacing a part rather than buying a machine, confirm the model and serial number with our parts team on (713) 931-0006 before ordering.
Starting points for the AirCoat systems:
−16%
−5%
The Short Version
Decide the air supply first: air-powered with a compressor (423, 620) or electric with an onboard compressor (AAA, MultiFinish 440). Then match delivery: 1.25 GPM for the 620, 0.58 GPM for the MultiFinish, 0.50 GPM for the 423, 0.35 GPM for the AAA. Order replacement parts from the diagram for your own model, because the four do not share a pump.
