The Maxum Elite parts list on our site has 50 parts. The ones that wear or get adjusted fall into three groups: the air valve seals and spring (callouts 6, 7, 9, 10 and 11), the needle group with needle packing 0275579 at callout 42, and the air nozzle #3 and air cap #3 at callouts 48 and 49. The cup is a separate 15-part diagram.
The Elite diagram
The Maxum Elite HVLP Spray Gun Parts List shows the gun body and head, with 50 parts. The cup is not on it: the cup, lid, gasket and tubes are on the separate Cup Assembly (P/N 0524271A) page, which lists 15 parts. The Maxum Elite HVLP Spray Gun page is the starting point if you want to see the gun first.
Titan describes the Elite as a gun for contractors and finishing professionals. Titan states several features that show up as parts on the diagram: an integrated check valve in the gun head, a fluid needle that stays with the packing and head assembly when you change colour or tip size, and a #3 Pro Set as standard. The callouts below are copied from the diagram as printed.
Air valve group
Air valve parts
These are the same names and numbers you see on the Maxum II diagrams, which is useful if you own both guns. The Elite list also has its own air flow valve, 0524491, with a different number from the Maxum II's 0277493, so do not mix those two.
Needle group
Needle group parts
We group these because Titan says the needle stays with the packing and head assembly on the Elite. The grouping is ours, not Titan's. The parts list also names a needle packing adjustment nut (0524485), a needle adjustment detent (0524489), a material flow adjustment knob (0524490) and a rear needle (0524505A). Check their callouts on the page itself.
Nozzle and cap
Nozzle and air cap parts
The diagram lists a #3 nozzle and #3 air cap, and Titan ships a #3 Pro Set as standard. For other sets, the site lists a 0524284A Needle Assembly #4 and Elite projector sets (#3 is 0524294, #4 is 0524295, #5 is 0524296, #6 is 0524297 and #7 is 0524298). Titan lists sets #2 to #7 for the Elite, from 524293 to 524298.
The rest of the list
Other names on the 50-part list include the 0524272A Gun Head PKG, gun body insert 0524612, gun body O-ring 0524618, gun body/head seal 0524503, check valve retainer with O-ring 0529220, trigger lever 0524615, trigger pin 0524697, air cap ring 0524484 and gun head latch 0524084. These are for damage, not routine replacement; we give no callouts here because the printed page is the reliable reference.
Kits
Titan lists Maxum Elite maintenance kits as Standard 524188 and Deluxe 524189, described as a way to store multiple projector sets, seals and check valves in one spot. The contents are not listed in the material we work from, so check the product page or ask us. Gun and cup kits that appear on the site include the 0297051 Check Valve Repair Kit and the 0297052 Cup Gasket Kit.
Is repair or replace the right call
The Elite diagram sells its wear parts one at a time: needle packing, needle spring, the air valve seals, the nozzle and the air cap are all separate numbers, so a worn seal does not mean a new gun. Match the symptom to the part. Titan's Maxum II manual ties leaking and pulsing to the packing, and spitting and no flow to the check valve, so those are the first parts to look at before you order anything else. The Elite has its own manual: use it for its own steps.
Elite parts and projector sets from this guide:
The Short Version
Three groups cover most of the Elite's wear: air valve seals and spring, the needle group (packing 0275579 at callout 42), and the #3 nozzle and air cap. Cup parts are on their own diagram. Everything is sold as an individual part.
