The Titan Elite 3000 (2402333) is an electric sprayer with a 1.2 HP DCX motor. Titan lists 3300 psi maximum pressure, 0.60 gpm maximum delivery, a 0.025 in. maximum tip with one gun and a recommended 75-100 gallons per week. It ships with an RX-Pro gun, a 517 tip and a 1/4 inch x 50 ft airless hose.
Elite 3000 at a glance
These are the figures Titan publishes for the Elite 3000, taken from Titan's own product page. Where sources disagree, we leave the number out and say so.
Titan Elite 3000 specifications
| Spec | Titan lists | In practice |
|---|---|---|
| Titan part number | 2402333 | The number to give when you phone about parts |
| Power | Electric, 1.2 HP DCX motor | Needs a suitable power supply and extension cord |
| Maximum operating pressure | 3300 psi (22.8 MPa) | Every hose, whip and fitting in the line must be rated for it |
| Maximum delivery | 0.60 gpm (2.3 LPM) | The most paint the pump can deliver in a minute |
| Maximum tip, one gun | 0.025 in. | The largest orifice Titan lists for this model |
| Recommended volume | 75-100 gallons per week | Titan's figure for how hard to work it |
| Included | RX-Pro gun, 517 tip, 1/4 inch x 50 ft airless hose | Ready to spray when you add paint and power |
Figures are from Titan's Elite 3000 page. The manual for your sprayer is the reference for anything not shown here.
What the tip limit means for your coatings
The orifice size of the tip controls how much material is delivered. Thicker coatings generally need larger orifices, and fine finishes use smaller ones. The Elite 3000's maximum is 0.025 in. A larger orifice asks for more paint per minute, and this pump's maximum delivery is 0.60 gpm, so a coating that needs a bigger tip than that belongs on a bigger sprayer.
A worn tip changes the picture. The orifice widens, pressure falls, the pattern coarsens and you use more paint. Change tips when the pattern degrades. The 661-020 tip seat and seal kit (5 pack) is on the Elite 3000 accessories page.
Coatings. Titan's Elite 3000 page lists no coatings, so we do not give a list. Check your manual and the coating maker's data sheet before spraying a material you have not used on this machine, and call us if the manual is unclear.
What Titan says about how it is built
- PermaStroke technology: Titan says there is no piston, packings, cylinder or clutch to wear or burn out, and that it delivers top performance between 300 and 3300 psi. It is a sealed hydraulic pump.
- Field serviceable: Titan says the Elite 3000 has only two wear parts to change. The Titan text we reviewed does not name them, but the site's pump diagram lists the 2393043 inlet valve and the 2369445 outlet valve assembly.
- Sureflo pusher valve: Titan says it lets you release a stuck lower ball valve without using a hammer.
Cart, tires and set-up
Titan describes a multi-position cart that supports either a low rider siphon set-up or a high rider direct immersion set-up, running on 10 inch pneumatic tires. The site lists the cart parts on its Elite 3000 cart assembly page, including the 2402496 handle assembly. The complete cart is 2402523 on the main assembly page.
What is in the box
Titan lists an RX-Pro gun, a 517 tip and a 1/4 inch x 50 ft airless hose with the Elite 3000. The site's 0538020 RX-Pro is the replacement gun, and the accessory page also lists filters such as the 730-067 60 mesh manifold filter. Everything the box does not hold is on Elite 3000 accessories.
Numbers we do not give
Some figures you may see elsewhere are missing here because we could not verify them.
- Weight. Sources disagree on it, so we give none.
- Coating list. Titan's page names none.
- Hose length limit and noise level. Neither is published on Titan's page.
- Hours or gallons of service life for any pump part. Titan does not publish one.
Gallons per week is Titan's recommendation, not a measured limit. Dealer figures differ, so we use Titan's.
Where to find parts and the manual
The Elite 3000 has a diagram page for each assembly, from the pump assembly to the hopper and the suction sets. Open the page, find the numbered callout and add the part. The owner's manual, with the pressure relief procedure and troubleshooting, is on our manuals page. For fitment questions call (713) 931-0006 with the serial number.
Elite 3000 sprayer and parts to start from:
−16%
−15%
The Short Version
The Elite 3000 is a 3300 psi, 0.60 gpm electric hydraulic sprayer with a 0.025 in. maximum tip and a Titan-recommended 75-100 gallons per week. Check your tips and your coating against those numbers and the manual, and order parts from the Elite 3000 diagram pages.
