The PowrBeast 7700 230V (Titan part 537003) is listed at 1.6 gpm (6.0 L/min) and 3300 psi (22.8 MPa), driven by a 4.1 HP TEFC DC motor, and is rated for up to 4 guns. The electric-side parts on the site's diagrams include the 9953704 on/off switch and the 0537477 DC electric belt. The fluid section and hydraulic filter are shared with the gas 7700.
Titan's specs
The figures below are from Titan's page for the PowrBeast 7700 230V, part 537003. Titan describes the series as hydraulic-drive, direct immersion airless sprayers, and the 230V model is the electric version of the 7700.
PowrBeast 7700 230V electric, as listed by Titan
| Item | Listed figure |
|---|---|
| Maximum delivery | 1.6 gpm (6.0 L/min) |
| Maximum operating pressure | 3300 psi (22.8 MPa) |
| Motor | 4.1 HP TEFC DC motor |
| Maximum tip, 1 gun | 0.043" |
| Maximum tip, 2 guns | 0.031" |
| Maximum tip, 3 guns | 0.023" |
| Maximum tip, 4 guns | 0.021" |
| Guns | Up to 4 |
| Included | RX-Pro gun, 517 TR1 reversible tip, 1/4" x 50' airless hose |
Tip sizes are maximums for the number of guns, not recommended tips. Check the power supply requirements in your manual before you plug in.
The 12-inch pneumatic tires and telescoping handle are common to the whole PowrBeast series. For the voltage and electrical supply your sprayer needs, use the operating manual on our manuals page rather than a spec sheet summary.
What it sprays
Titan's page says the 7700 230V sprays stains, lacquers, epoxies, enamels, elastomeric, latex, dry fall and block fillers, and recommends it for large projects or heavy coatings. Different coatings need different tip sizes, so choose the tip for the coating and keep it at or under the limit for the number of guns you run. Thin only as the coating manufacturer allows.
Features Titan lists
- HydraStroke Technology: Titan calls it digitally driven hydraulics with one moving part, reducing heat and extending life, with no clutch to burn out.
- Severe Service fluid section: a long, slow-stroking piston that is field serviceable and easy to remove and replace.
- Cooling: a fan and shroud move air over warm areas, and the hydraulic tank is radiator-style and actively cooled.
- Front-mounted motor and pump assembly: easy access for maintenance and service.
- Submersed foot valve: listed by retailers for the 7700 to improve suction on heavy graded materials.
Electric-side parts on the diagrams
Most of a PowrBeast 7700 is common to gas and electric, and the site's 7700 diagrams are shared. A handful of parts are the ones that belong to the electric version, and they are listed on the two main assembly pages.
Electric-side parts
Open Main Assembly I for the switch, belt and lamp, and Main Assembly II for the motor tray, wheels and solenoid. If you are replacing a drive part, match the callout on the page to the part in your hand before you order.
Parts shared with the gas 7700
The pump end is the same on gas and electric, because the 7700 diagram pages cover both. The fluid section is listed as assembly 0537256 on the fluid section diagram, with the 138-153A repacking kit and the usual packing springs, valve seats and balls. The hydraulic side is shared too, including the 451-220 hydraulic filter on the 7700 hydraulic system page.
For hydraulic fluid, Titan's Coolflo (430-361 by the gallon) is made for sealed hydraulic sprayers and is described as giving cooler pump operation and protection against rust and oxidation. The fluid level, type and change schedule for your sprayer are in the manual, so follow it rather than a general rule.
Gas versus 230V
PowrBeast 7700: gas and 230V as listed
| Item | 7700 gas | 7700 230V |
|---|---|---|
| Maximum delivery | 2.0 gpm | 1.6 gpm (6.0 L/min) |
| Maximum pressure | 3300 psi | 3300 psi (22.8 MPa) |
| Power | Honda GX200 (200 cc) | 4.1 HP TEFC DC motor |
| Tip, 1 gun | 0.047" | 0.043" |
| Tip, 2 guns | 0.033" | 0.031" |
| Tip, 3 guns | 0.027" | 0.023" |
| Tip, 4 guns | 0.023" | 0.021" |
| Guns | Up to 4 | Up to 4 |
Pressure and gun count match. The gas unit delivers more, so it carries a larger tip allowance at every gun count. If you spray on a site without suitable power, a gas model is the usual answer, and the gas engine must be run and fuelled outdoors or in ventilated areas only.
Ordering
Confirm it is the 230V
Check the model tag. If your sprayer has an engine instead of a motor, you have the gas 7700 and the switch and DC belt above do not apply.
Open the right page
Use Main Assembly I or II for the electric-side parts, and the fluid section page for pump parts.
Match the callout
Add the part from the numbered callout, or search by part number in the site header.
Call if unsure
Phone (713) 931-0006 with the model and serial number and what the sprayer is doing.
Parts for the 230V and the shared pump side:
On/off switch, DC electric belt, control lamp, top shroud.
Electric motor tray, wheels, solenoid and pulley.
Repacking kit, springs, valve seats and balls.
Every PowrBeast diagram page.
The Short Version
The 7700 230V is listed at 1.6 gpm and 3300 psi with a 4.1 HP TEFC DC motor and up to 4 guns. Switch, DC belt, lamp and motor tray are the electric-side parts, and the fluid section and hydraulic filter are shared with the gas 7700.
