Retail listings describe the PowrBeast 4700T as a sprayer for textures and mastics. On this site it shares the 4700 diagram pages, which are all titled 4700/4700T, and it has its own 537268 fluid section listing. Sources disagree on its power source and unit number, so we do not state either. Check the label on your machine or call us.
What the 4700T is marketed for
Retail listings put the 4700T in a different job from the standard 4700. Sherwin-Williams lists it as a sprayer for textures and mastics, and other retailers sell it as a texture sprayer. Titan's description of the standard 4700 and 9700 is heavy bodied coatings on large residential or commercial jobs. So the dividing line is the material you spray: texture and mastic work for the 4700T, heavy bodied paint for the 4700.
It sits inside the PowrBeast series, and the series features Titan describes for the family apply to its listings too: HydraStroke Technology, digitally driven hydraulics with one moving part and no clutch to burn, and the Severe Service fluid section with a long, slow-stroking piston. Retailer listings for the 4700T also mention a submersed foot valve for heavy graded materials, the same wording used for the 7700 and 9700. We do not know how that wording maps onto the foot valve parts on the diagram, so we do not equate the two.
What the diagrams share
The site does not have a separate set of diagram pages for the 4700T. Every 4700 page is titled 4700/4700T, so the same pages cover both models:
Diagram pages titled for both the 4700 and the 4700T
| Assembly | Page | Key parts |
|---|---|---|
| Fluid section | Fluid Section (P/N 0537255 / 0537268) | 106-002A Repacking Set, 0537254A foot valve assembly |
| Bleed valve | Bleed Valve Assembly | 944-009 housing, 944-011 stem |
| Bleed valve, heavy materials | Bleed Valve Assembly, heavy materials | 945-600A bleed valve, 945-906 seat |
| Main assembly | Main Assembly I and Main Assembly II | Shrouds, motor / pump assembly, engine and motor parts |
| Hydraulics | Hydraulic System, Hydraulic Motor, Solenoid | 451-220 filter, 0537207A solenoid |
| Filter, cart, accessories | High Pressure Filter, Cart, Accessories | 930-050 filter service kit, 661-020 tip seat kit |
Because the page titles name both models, the page cannot tell you which model a given callout was drawn for. Compare the picture with your part.
What is specific to the 4700T
The clearest model-specific item on the site is the fluid section. 537268 is listed as a fluid section assembly for the PowrBeast 4700T, and the diagram page covers it alongside 0537255. Titan's own fluid section page names 537255 for the PowrBeast 4700. We do not say whether 537268 and 0537255 are interchangeable, so if you are buying a complete fluid section, confirm the number with us first.
Below the assembly the parts on the page are listed once for both, including the 106-002A Repacking Set and the 0537254A foot valve assembly. The 4700T bleed valve question is similar. The site has two bleed valve pages for the 4700/4700T, a standard one and a heavy materials one with the 945-600A bleed valve. We do not claim which of the two is fitted to which unit; match the picture to what is on your machine.
What we cannot say
The sources we have checked do not agree on two basic facts about the 4700T, so we do not state them:
- Power source. Some listings call it electric and one retailer names it a gas mechanical texture sprayer.
- Unit part number. The listings give different numbers for it.
- Flow and tip limits. Delivery and maximum tip size depend on whether the machine is gas or electric, so we do not quote them for the 4700T.
- Weight and weekly volume. The figures for these conflict between sources, so we leave them out.
The label on your machine is the way to settle all of this. If you have a 4700T and need a part, the model and serial number on that label are what we need when you call (713) 931-0006. Manuals are on our manuals page.
Heavy coatings and wear
Thick materials such as textures and mastics ask more of a pump than thin paint does, so the packing and valve parts on the fluid section page are the ones to watch. Worn packings show as leaking at the wet cup, paint in the wet cup, or pressure that will not hold, and worn valves show as pulsing, pressure loss or failure to prime. Titan does not publish a service life for PowrBeast fluid section parts, so replace on symptoms, not on a calendar. Keep the wet cup filled with 314-480 Piston Lube as the manual describes, and flush the pump after every job; never leave a coating to dry in the pump, hose or gun.
Where to look for 4700T parts
Read the label
Note the model and serial number so you can tell us which machine you have.
Pump parts: the fluid section page
Packings, springs, seats, balls and the 537268 assembly are all on one page.
Bleed valve: compare both pages
Open the standard and heavy materials pages and match the picture to your valve.
Everything else: the shared 4700/4700T pages
Hydraulic, solenoid, filter, cart and accessories pages are shared, so pick the callout that matches your part and call if you are unsure.
Parts the 4700T and 4700 diagram pages share:
−15%
The Short Version
The 4700T is sold for textures and mastics and shares every 4700 diagram page. Its own listing on this site is the 537268 fluid section. Power source and unit number are not settled by the sources, so read your label and call us when a part depends on it.
Not sure whether you have a 4700 or a 4700T?
Call (713) 931-0006 with the model and serial number from the label and our parts team will confirm the part before you order.
