The Titan CAPSpray Maxum Elite is an HVLP spray gun in Titan's fine-finish line, supplied with the CapSpray 105 and 115 turbine systems and used for fine-finish coating work in cabinetry, woodworking, and trim.
Maintaining the Maxum Elite correctly means understanding which components wear and on what schedule, how to identify them from the parts diagram, and what to have on hand before finish quality degrades on a job.
Maxum Elite Gun — Component Anatomy
Key Serviceable Components
Diagnosing Finish Quality Problems
Common Maxum Elite spray quality problems and their usual causes:
- Coarse or orange-peel atomization — usually projector set viscosity mismatch or insufficient turbine air pressure. Try the next projector set size for thicker materials.
- Material dripping after trigger release — worn needle or needle packing. Check the needle tip for deformation first, then inspect the packing.
- Irregular fan width or split pattern — worn or partially clogged nozzle. Replace the needle and nozzle as a matched set.
- Air before fluid at stroke start — air valve timing issue. Inspect and replace the air valve assembly.
Cleaning and Maintenance That Extends Service Life
HVLP guns are often used with solvent-based coatings and lacquers, so thorough cleaning after every use is an important maintenance habit for the Maxum Elite.
After each session: flush with the appropriate cleaning solvent for the material used, disassemble the needle and nozzle, clean the air cap passages with a soft brush (never a wire brush or pick), and dry all components before reassembly. Coating material allowed to dry in the nozzle or air cap passages changes the spray pattern on the next use and can look like wear when it is really just contamination.
The complete Titan Capspray parts catalog at AllTitanParts.com includes needle and nozzle sets, projector sets, needle packing, trigger assemblies, and air valve components for the Maxum Elite and Maxum II. For components across the broader airless sprayer parts range, the same site covers both finishing and production spray equipment.
When to Replace vs. When to Rebuild
Unlike airless fluid sections where a complete rebuild restores the machine to like-new specification, HVLP gun maintenance is more a matter of individual component replacement as wear becomes visible in finish quality.
The practical decision: replace the needle and nozzle as a matched pair when atomization quality declines, replace the needle packing when material leaks around the needle shaft, replace the trigger when trigger response becomes inconsistent. The air valve and spring are replaced when air timing is noticeably off and cleaning doesn't resolve it.
The gun body is a structural housing rather than a wear component. If it is cracked or thread-damaged, replacement is appropriate; otherwise component-level service is the usual approach.
