The CapSpray 95 (Titan 524032) is a 4-stage electric HVLP turbine system with a 9.5 psi maximum air pressure. Titan ships it with a 30 ft air hose, a Maxum II gun and a #3 pro set. Its parts sit on four diagrams: Main, Turbine, Upper Housing and Lower Housing. The X 95 adds a CapLiner System to the same 4-stage, 9.5 psi base.
What comes with the CapSpray 95
Start with the box, because most 95 questions come down to what was supplied and what has to be bought separately. Titan's page for the 95 lists the following.
CapSpray 95 as Titan lists it
| Item | CapSpray 95 |
|---|---|
| Titan part number | 524032 (0524032 on our site) |
| Turbine | 4-stage |
| Maximum air pressure | 9.5 psi |
| Air hose | 30 ft |
| Gun | Maxum II |
| Projector (pro) set | #3 |
Weight and current draw are not listed here because published figures conflict. Your owner's manual gives the electrical details.
The site's diagrams match the box. The 95 Main Assembly page lists the 0524041 Maxum II gun with cup and the 0277337 flex hose assembly, 30 ft, and it has no whip hose, which is consistent with a 30 ft hose and nothing else. The 105 and 115 pages list a 5 ft whip hose (0524405A) as well, because those boxes include one.
A pro set is the needle, fluid nozzle and air cap that work as a matched group, and a larger set number is a larger nozzle opening. The Maxum II adjusts air, fluid, fan size, orientation and shape, so one gun covers pencil-thin and wide fan patterns. For which set to pick, the viscosity cup and the chart in your manual are the way to decide.
What Titan says the 95 is for
Titan describes the 95 as a versatile 4-stage turbine unit for a wide range of coatings, from ultra-thin stains up to heavy latex paint. It also says the 95 has a longer hose and more advanced noise control than the 75.
Treat that range as a ceiling on what the machine can atomize, not as permission to skip the coating maker's instructions. Thin only as far as the coating's own data sheet allows, strain before you pour, and check viscosity with the 0153165 viscosity cup, which is listed on the 95 Main Assembly page.
Features that come with the unit
- An automotive-type air filter, plus a pre-filter on both the atomizing-air and cooling-air sides.
- A dirty-filter warning light that comes on when air flow drops. Per the manual it does not shut the turbine down, so act on it.
- An onboard toolbox for needles, nozzles, air caps and the nozzle wrench, and a built-in gun and cup holder.
- Sound reduction technology, and a transfer efficiency Titan puts at up to 90%.
The X 95 as the sister model
The CapSpray X 95 (Titan 2458984) shares the 95's base figures: a 4-stage turbine, 9.5 psi, a 30 ft hose and a #3 pro set. Titan sells it as an entry-level unit for tub refinishing and clear fine finishes, and what it adds is the CapLiner System and wrap tabs on the filter cans for power-cord management.
CapSpray 95 and X 95, as Titan lists them
| CapSpray 95 | CapSpray X 95 | |
|---|---|---|
| Turbine and pressure | 4-stage, 9.5 psi | 4-stage, 9.5 psi |
| Air hose | 30 ft | 30 ft |
| Gun | Maxum II | Maxum II with CapLiner System |
| Pro set in the box | #3 | #3 |
| Extras | None listed | CapLiner kit, wrap tabs on the filter cans |
The CapLiner kit in each X sprayer is one reusable cup, one reusable retaining ring, one adapter, and four each of disposable lids, liners and plugs. Do not assume parts swap between the two: the X 95 has its own diagram pages, and its Main Assembly page lists different filter can and cover numbers (0276136A and 2441512A) from the 95's (0524948A and 0524949A). Order from the page for the sprayer you own.
Parts by assembly
CapSpray 95 diagram pages
| Diagram page | Parts listed | Key parts |
|---|---|---|
| Main Assembly | 17 | Filter can, cover, pre filter kit, pleated air filter, two silencer assemblies, gun, flex hose, viscosity cup |
| Turbine Assembly | 9 | 0524289A 4-stage turbine, 0277243 brush kit, can seal, spring, spacers |
| Upper Housing | 21 | 0524553 on/off switch, 0524549 breaker kit, air flow switch, warning light, handles, toolbox |
| Lower Housing | 7 | Power cord assembly, exhaust hose, fitting, clip, foot pad |
The X 95 pages are separate: start from the X 95 Main Assembly if you own that model.
Two details on the 95 Main Assembly page are easy to miss. It lists both the 0524593A silencer assembly and a second silencer assembly, 0524926, which the 75 page does not carry. It also lists the 0524523A pleated air filter next to the 0524528A, which our diagrams call the Turbine Motor Air Filter. Titan's accessory page uses a different name for 0524528A, so go by the callout and ask us if the names look contradictory.
The turbine page lists the 0524289A 4-stage turbine assembly, 120V. The X 95 turbine page lists the same number, but we do not state fitment beyond what each diagram shows, so confirm by phone before treating any turbine as interchangeable.
Care in one paragraph
Clean the filters when the warning light comes on: unplug the unit, turn the covers counterclockwise, and tap out or blow out the pre-filter and filter on each side, because clogged filters cause excess heat that can damage the turbine. Titan's manuals for the 95, 105 and 115 ask for a brush check by an authorized service center every 400 hours, and the gun and cup should be emptied and cleaned after every use. Your manual, on our manuals page, has the full procedures.
The CapSpray 95 items most often ordered from this guide:
The Short Version
The 95 is a 4-stage, 9.5 psi turbine with a 30 ft hose, a Maxum II gun and a #3 pro set. The X 95 keeps those figures and adds CapLiner. Whichever you own, order from that model's own four diagram pages and confirm any shared-looking part by phone.
