Titan positions the PowrLiner 850 for smaller jobs and entry-level contractors, the 3500 for working striping contractors, and the hydraulic 4955, 6955 and 8955 for medium to large projects. The real separators are drive type, flow from 0.33 gpm up to 2.50 gpm, one or two guns, and engine size. Decide those four first, then match a model.
Start with the job, not the model
Titan's own positioning is the most reliable starting point, because it comes from the people who built the range. The PowrLiner 850 is aimed at smaller jobs on pavement, grass or turf, and at entry-level contractors, turf managers and maintenance crews. The 3500 and the models above it are aimed at striping contractors, and Titan describes the 4955 as a machine for medium to large striping projects.
Titan does not publish square footage or gallons-per-week figures for any of these, and we are not going to invent them. What you can do is describe your work in four plain terms: how often you stripe, how many gallons you move on a typical day, whether a second gun speeds you up, and how far you have to carry or haul the machine. The sections below turn each of those into a specification you can compare.
What the numbers say
All five models share a 1/4 in. x 50 ft hose from the factory. What changes is the drive, the pressure ceiling, the delivery and the engine.
PowrLiner models side by side (Titan data)
| 850 | 3500 | 4955 | 8955 | |
|---|---|---|---|---|
| Drive | Clutch-driven piston pump | PermaStroke sealed hydraulic, no clutch | Hydraulic, slow-stroking | Hydraulic |
| Max pressure | 3000 psi | 3300 psi | 3300 psi | 3300 psi |
| Max delivery | 0.33 gpm | 0.75 gpm | 1.25 gpm | 2.50 gpm |
| Engine | 37.7 cc 4-stroke | Honda GX120 | Honda GX120, pull start | Honda GX200, electric start |
| Guns supplied | 1 (LX-40) | 1 (RX-80) | 2-gun configuration, S-3 guns | 2-gun configuration, S-3 guns |
| Weight | Sources disagree | Sources disagree | 324 lbs | 339 lbs |
The 6955 sits between the 4955 and 8955 with a Honda GX160 and electric start, at 334 lbs. Its delivery and tip figures differ between Titan's page and dealer listings, so check Titan's spec sheet for those. Weights for the 850 and 3500 also differ between sources, which is why they are not stated here.
Two things in that table matter more than they look. The first is pressure: the 850 tops out at 3000 psi and every other model at 3300 psi. The second is delivery, which runs from 0.33 gpm on the 850 to 0.75 gpm on the 3500 and up to 2.50 gpm on the 8955. More delivery lets you run a larger tip or a second gun without starving the pattern. Titan lists the 4955, 6955 and 8955 for coatings from light-bodied paints up to low-VOC striping paints, and the 3500 for latex and oil-based field and pavement marking coatings.
Drive type decides what you will maintain
The drive matters for buying because it decides which parts you will eventually replace. The 850 is clutch-driven and uses a piston pump, so its diagram lists a repacking kit, a piston rod, seals and a clutch assembly. The 3500 uses Titan's PermaStroke system, which Titan describes as having no piston, packings, cylinder or clutch to wear or replace, with two field serviceable wear parts. The 4955, 6955 and 8955 use a hydraulic drive that Titan calls slow-stroking, and they need Coolflo hydraulic fluid and packing lubricant as routine consumables.
None of those is better in the abstract. Fewer wear parts suit a crew that stripes on short notice. A hydraulic machine suits a crew that wants more flow and two guns and will keep up with fluid checks. To see the difference in actual parts, open the 850 drive assembly and the 3500 pump assembly side by side and the difference is obvious.
What comes in the box
- 850: one LX-40 gun, a 419 tip and a 1/4 in. x 50 ft hose. The 850 can carry a 5-gallon pail, and Titan says it fits in most car trunks and needs one operator.
- 3500: one RX-80 gun, a 419 line striping tip and a 1/4 in. x 50 ft hose, on a frame that swings back, with 16 in. pneumatic tires, a removable gun for stencils and two tip holders.
- 3500S: the same pump, with a second RX-80 gun on an extension, a short hose and a stenciling tip for stencil work (dealer listings).
- 4955, 6955 and 8955: a 2-gun configuration with S-3 guns and a 1/4 in. x 50 ft hose. All three have a 12-gallon paint hopper, a 300 ft hose rack, a SmartArm gun mount and adjustable handlebars.
A second gun is not free capacity. Titan lists the 8955 at a 0.054 in. maximum tip with one gas gun and 0.038 in. with two, since two guns draw on one pump. Treat the second gun as a way to stripe two lines in one pass, not as a way to keep a big tip.
Walk-behind or ride-on
If the job list includes long runs of parking lot or curb, a LazyLiner turns a walk-behind striper into a ride-on. Titan states it is compatible with the PowrLiner 2850 and up, and our catalog lists the LazyLiner Pro and Elite against the 5500, 4955, 6955, 8955, 4500, 3500 72V and 3000/3500S. The 850 and 550 are not named in either list, so call before assuming one fits. The hitch is a separate purchase. See the LazyLiner parts page, and for the machines themselves the LazyLiner Pro 0290041H.
Think about parts support before you buy
Every model above has diagram pages on this site, so wear parts and manuals stay available whichever you choose. The pages worth knowing before you buy are the drive or pump page, the gun page and the accessories page. For the 850 that is the drive assembly and the accessories page; for the 4955 it is the main assembly and its fluid section.
Whichever model you pick, a few cheap spares cover most early downtime: a spare 697-419 tip (the 419 that ships with the 850 and 3500), a tip seal such as 651-020, and a gun filter. The 850 lists a 581-060 white filter on its gun page. The 3500 lists a 0089957 coarse gun filter.
Questions to answer before you buy
How wide are your lines?
A dealer page built from the manual gives the 850 a line width range of 2 in. to 12 in. If you routinely need something outside that, or two parallel lines at once, look higher up the range.
One gun or two?
The 850 and 3500 are one-gun machines out of the box. The hydraulic models come configured for two guns, and the 3500S adds a stencil gun.
Gas, electric or battery?
The 4955, 6955 and 8955 are gas, and dealers list electric versions too. Our diagrams include both a gas Convertokit and a DC-Electric Convertokit page for them. The 3500 72V is a battery version with a Honda eGX unit and no engine or fuel, per Titan's page.
How will you move it?
Titan says an 850 fits in most car trunks. A 4955 weighs 324 lbs and an 8955 339 lbs, so work out how you will load and haul it before you settle on a spec sheet.
Do you want to ride?
If yes, check the LazyLiner fitment above against the exact model you are considering, and confirm it with our parts team.
The complete units and starter items named in this guide:
−23%
−29%
The Short Version
Pick the 850 for smaller jobs and one operator, a 3500 or 3500S when you want more delivery with fewer wear parts, and a 4955, 6955 or 8955 when you need two guns and higher flow. Add a LazyLiner if you would rather ride. Call (713) 931-0006 with your model if you are matching parts to a machine you already own.
