The corded FlexSpray Handheld's accessories are its one-quart container and container seals, air and suction tube filters, valve and nozzle seals, needle kits, a cleaning brush and a carry case. The seals and filters are the small items to keep spare. Order from the Handheld's own diagram pages, because these parts are listed for the corded model.
The corded FlexSpray Handheld (model 0524093) has few moving parts, so most of what you will ever buy for it is an accessory: a container, a filter, a seal, a needle kit. This guide goes through the parts the site lists for it, says what each one does and which are worth carrying, and keeps them in one place so you can order in one go. Every part here is on the FlexSpray Handheld Parts List page or the accessories page. These are listed for the corded model, not for the cordless FlexSpray Pro 18V.
Material containers
The sprayer works from a container that screws on, so the container and its sealing parts decide whether it can build pressure. The diagram lists four:
- 0529925 Material Container (1 Qt), the one-quart container; Titan's description of the Handheld mentions a one-quart stainless steel cup.
- 0529924 Plastic Cup.
- 0529923 Container Seal, a 5 pack of gaskets.
- 0529927 Threaded Lid and Container Seal.
We do not describe how the plastic cup and the material container differ beyond their names. If you are unsure which one your unit uses, the numbered callouts on the parts list page show where each sits, or call (713) 931-0006.
Filters
Three filter parts are listed, and they protect different paths. The suction tube filters sit on the coating side: 0529916 is the fine one and 0529915 is a coarse 5 pack. The 0529243A Air Filter (3 pc) is for the air. Strain the coating, clean the filters after every job, and pick the fine or coarse filter to suit the coating, since a partly blocked filter causes pressure loss and spitting.
Seals and valve parts
These are the cheap wear items and the ones to buy ahead:
Seals and valve parts on the corded FlexSpray Handheld
| Part | Name on the diagram | Where it is listed |
|---|---|---|
| 0529921 | Nozzle Seal | Parts List, callout 7 |
| 0529922 | Front End Assembly O-Ring | Parts List, callout 8 |
| 0529926 | Valve Seal, 10 Pack | Parts List and accessories page |
| 0529920 | FlexSpray Air Tube and Valve Seal Kit | Parts List, callout 3 |
Titan publishes no service life for these, so replace one when it is damaged, flattened or the unit leaks at that joint.
Needle kits and front end parts
Each of the two front ends has its own needle kit, and they share one callout on the parts list. 0529245 is the Flex Finish needle kit for the white front end and 0529246 is the kit for the red Fine Finish front end. Buying the right one means knowing which front end you spray with. Titan assigns latex, enamel and acrylic to the white one, and stains, lacquers and urethanes to the red one.
The complete white front end is 0529009. Around it the diagram lists the 0529909 Air Cap, the 0529908 Spray Jet Kit and the 0529910 Fluid Nozzle (Flex Finish). The 0529911 Gun Body and the 2319222A Feed Tube are the larger pieces if something is cracked.
Carry and cleaning
A 0529248 Carry Case and a 2344464A Strap Shoulder are listed as parts. We have not verified what ships in the box with the corded model, so treat these as replacements and not as a statement of what is included. The 0529411 Cleaning Brush is the cleaning tool: Titan's manual says never to clean the nozzle or air holes with sharp metal objects, and the brush is the safe alternative.
A short list to keep
- A pack of valve seals (0529926) and a nozzle seal (0529921).
- The front end O-ring (0529922).
- A spare suction tube filter in the grade you use (0529916 or 0529915) and the air filter (0529243A).
- The needle kit for the front end you use most (0529245 or 0529246).
- A cleaning brush (0529411).
Match every order to the diagram for the corded model, and call (713) 931-0006 with the model and serial number if you are unsure. The wider fine finish group sits under FlexSpray Series Sprayer Parts, and the manual is on the manuals page.
Spares for the corded FlexSpray Handheld:
The Short Version
Keep seals, a filter and the right needle kit with the sprayer, and replace each when it is damaged or the pattern degrades, since Titan gives no life figure. Order from the corded model's diagram pages.
