Titan 805-254A Face Plate / Oiler Assembly
Maintain the pump's original service configuration with the Titan 805-254A Face Plate / Oiler Assembly. This OEM replacement assembly combines the designated face-plate and oiler arrangement used in compatible Titan sprayer pump systems. It provides a targeted replacement when the original assembly is damaged, worn, or requires servicing, helping maintain access to the pump's lubrication point and the proper fit of its associated components.
Service Purpose: Replacement of damaged or worn face-plate/oiler hardware.
Ordering Guidance: Confirm Titan part 805-254A in your machine's official parts diagram.
Restore the Original Face Plate & Oiler Assembly
The Titan 805-254A Face Plate / Oiler Assembly is a genuine OEM replacement component specified in the main assemblies of Titan Impact 740, 840, 840I, and 840IA electric airless sprayers. Combining the designated face-plate and oiler arrangement, this assembly supports the machine's original service configuration. It is intended for repairs involving damaged, missing, or otherwise defective face-plate/oiler hardware, with installation and lubrication procedures governed by the applicable Titan service manual.
What Does the Face Plate / Oiler Assembly Do?
The face plate/oiler assembly is a designated service component in the Titan Impact main assembly. Its combined construction provides the face-plate and oiler arrangement specified for the machine's pump and drive-area service configuration.
The face plate is secured using the mounting hardware identified in the manufacturer's exploded-parts diagram. The oiler portion is associated with the machine's prescribed lubrication and maintenance arrangement.
Because lubrication systems and service requirements vary between sprayers, use the exact Titan manual rather than assuming that this component is an adjustable compressed-air lubricator or that it accepts a universal oil specification.
When Should the Assembly Be Inspected or Replaced?
These conditions indicate a need for inspection, not automatic proof that the face plate/oiler assembly has failed.
Installation & Maintenance Guidance
1. Prepare the sprayer. Switch off the machine, disconnect electrical power, and follow Titan's pressure-relief procedure before servicing any pump-area components.
2. Verify fitment. Confirm part 805-254A and the correct diagram position for your Impact model and service-manual revision.
3. Inspect the mounting area. Examine adjacent housing surfaces and the four designated face-plate screws for wear or damage.
4. Install the replacement. Position the assembly correctly and use the specified mounting hardware, following any applicable manufacturer torque instructions.
5. Follow the lubrication procedure. Use only the lubricant type, quantity, and maintenance interval specified for the machine by Titan.
6. Inspect before returning to service. Check the completed assembly and perform the manufacturer's prescribed operational checks.
Why Choose the Correct Titan OEM Assembly?
Documented Fitment: Identified by part number in the manufacturer parts diagrams for supported Impact models.
Targeted Repair: Replace the specified face plate/oiler component without assuming the complete pump requires replacement.
Service Consistency: Maintain the manufacturer-designated assembly arrangement during professional maintenance.
Accurate Ordering: Distinguish part 805-254A from other similarly named Titan face plate/oiler assemblies.
Order Titan 805-254A Face Plate / Oiler Assembly
Choose the genuine Titan OEM replacement specified for your machine. Review the applicable parts diagram, inspect the four face-plate screws, and confirm your sprayer configuration before ordering from AllTitanParts.
Frequently Asked Questions
Answers about Titan 805-254A compatibility, mounting hardware, and maintenance.
What is Titan 805-254A?
It is a genuine Titan OEM face plate / oiler assembly identified in the main-assembly parts lists for compatible Impact sprayers.
Which Titan sprayers use this assembly?
Documented applications include Titan Impact 740, Impact 840, Impact 840I, and Impact 840IA.
Where is the assembly located?
It is listed in the machine's main assembly at the designated face-plate/oiler position.
Which screws secure the face plate?
The reviewed Titan diagrams identify four Titan 700-139 face plate screws as separate mounting hardware.
Are the four mounting screws included?
The screws are listed separately in the machine's parts diagram. Confirm package contents before ordering.
Is Titan 805-254A interchangeable with Titan 805-250A?
Interchangeability is not established by the reviewed documentation. Use the part number specified for your exact sprayer model.
What lubricant should I use?
Follow the lubricant specifications and maintenance instructions in your exact Titan machine manual. The parts-list description alone does not identify a universal lubricant grade.
Does this assembly replace the complete fluid section?
No. The face plate/oiler assembly and the fluid section assembly are separately listed service components.
