Titan 805-213A Left Leg Assembly
OEM Titan Stand and Skid Component
Titan 805-213A Left Leg Assembly is an OEM replacement that forms the left side of designated Titan stand and skid frames, providing structural support and stability on compatible Impact and RentSpray sprayers.
Compatibility Table
A stand or skid application does not establish compatibility with a wheeled cart version of the same model. Confirm 805-213A in the exact frame diagram before ordering.
Titan Stand and Skid Service Parts
Titan 805-213A Left Leg Assembly for Sprayer Frame Support
Titan 805-213A is the left support-leg assembly used in designated Titan stand and skid frames. It provides the left-side structural member that, together with the opposite support and correct hardware, holds the sprayer in its working position.
| Detail | Technical / Commercial Information |
|---|---|
| Product Overview | OEM Titan left leg assembly for designated stand and skid frames. Provides the specified left-side structural support on compatible sprayer configurations. |
| Function | Forms the left support member in the specified stand or skid frame. Together with the opposite support and correctly fitted hardware, it holds the sprayer in its working position. The documented arrangements also associate the left leg with cord-storage components. |
| Specification | Welded steel assembly. The referenced Impact 440 skid diagram groups the left leg, foot, plug, cord wrap, and cord-wrap screws under this reference. Included components should be checked against the applicable diagram and current package contents. Exact dimensions not independently established. |
| Industrial Applications | Professional airless sprayer frame repair, stand and skid restoration, and rental fleet equipment maintenance. |
| Compatible Titan Machines | Documented applications include specified Impact 410, 440, 540, 640, 640I, 640IA, and RentSpray 600 configurations. Confirm 805-213A in the exact frame diagram. A stand or skid application does not establish compatibility with a wheeled cart version of the same model. |
| OEM Part Number | 805-213A Left Leg Assembly. |
| Related Components | Right leg assembly; feet and end plugs; mounting fasteners; cord wrap; drip cup and nearby fittings. These are separately identified components and are not included with the left leg assembly. |
| Common Problems Solved | Bending or distortion; cracks or joint damage; structural corrosion; damaged mounting features; uneven support causing rocking. |
| Target Users / Markets | Painting contractors, equipment maintenance technicians, rental fleet operators, and repair shops servicing compatible Titan airless sprayers. |
| OEM & Brand Information | Genuine Titan OEM left leg assembly designed for correct fitment in specified stand and skid frame applications. |
| Commercial Benefits | Restores structural integrity and stability; ensures proper frame alignment; model-specific part number simplifies ordering; maintains safe sprayer operation. |
Follow the applicable manual shutdown and pressure-relief procedure, then isolate the power source. Check that the installed stand or skid diagram specifies 805-213A. Support the equipment securely before removing a structural support. Inspect the opposite leg, mounting points, fasteners, and ground-contact parts for damage. Use the specified hardware and tightening instructions. Confirm which accessories are included and which require transfer or separate replacement. On a suitable level surface, verify secure attachment, correct clearance, and stable support before following the manual return-to-service procedure.
Frequently Asked Questions
Quick answers for confirming fitment and service requirements.
