Titan 697-423 TR1 823 Line Striping Tip
TITAN TR1 REVERSIBLE LINE STRIPING TIP
Titan 697-423 TR1 423 Line Striping Tip combines a 4-inch nominal stripe with a .023-inch orifice for heavy-film application with most traffic paints. Its reversible airless design supports professional pavement marking, controlled material delivery, and convenient tip clearing.
Titan classifies 697-423 for heavy-film use with most traffic paints. Do not confuse it with Titan 697-823: both use a .023-inch orifice, but 697-423 produces a 4-inch nominal stripe while 697-823 produces an 8-inch nominal stripe.
| Detail | Technical / Commercial Information |
|---|---|
| Product Overview | Titan 697-423 is a genuine TR1 reversible airless line-striping tip. Titan specifies a 4-inch / 102 mm nominal line width and .023-inch / .58 mm orifice. Official Titan TR1 charts classify the 423 as a heavy-film tip for most traffic paints. |
| Function | The .023-inch opening meters a relatively high volume of coating while the tip geometry concentrates that material into a 4-inch nominal marking pattern. Its reversible configuration allows the operator to rotate the tip to help clear certain obstructions before returning it to the normal spraying position. |
| Industrial Applications | Designed for professional pavement and traffic-marking applications requiring a conventional 4-inch stripe with heavy film. Potential uses include parking lots, commercial properties, industrial facilities, road markings and other professional striping work using traffic coatings approved for a .023-inch airless tip. |
| Accurate Compatible Titan Machines | Titan publishes 697-423 in official TR1 tip charts supplied with PowrLiner equipment, including PowrLiner 550, PowrLiner 850, PowrLiner 2850 and PowrLiner 3500 documentation. Actual machine compatibility depends on whether the specific PowrLiner supports a .023-inch tip for the number of guns being operated. |
| Accurate Part Number | Titan 697-423 — TR1 423 Line Striping Tip. This is not TR1 823. Titan 697-423 is the 4-inch / 102 mm, .023-inch / .58 mm heavy-film configuration; Titan 697-823 is a separate wider-pattern tip. |
| Compatible Parts & Assemblies | Use with a compatible Titan airless line-striping gun, reversible-tip guard, tip seal, appropriate gun and machine filtration, high-pressure hose and PowrLiner fluid-delivery system. The complete machine configuration must have sufficient output capacity for the .023-inch opening. |
| Related Parts Commonly Serviced Together | Inspect the compatible tip guard, tip seal and retainer, spray-gun filter, gun fluid passages, high-pressure hose, machine filtration and gun-positioning hardware when servicing the tip. Worn seals, restrictions or incorrect gun height can negatively affect stripe width, edge definition and material distribution. |
| Common Problems Solved | Replacing a worn 697-423 can help restore the intended 4-inch spray pattern when normal abrasive wear causes poor edge definition, excessive material delivery or fan-pattern deterioration. Its reversible design also assists with clearing certain tip obstructions encountered during production striping. |
| Use with Coating Systems | Titan categorizes 697-423 under “Most Traffic Paints” and specifies heavy-film application. Confirm that the selected traffic coating supports a .023-inch airless opening and follow its manufacturer's recommendations for pressure, filtration, viscosity, preparation and application conditions. |
| OEM & Brand Information | 697-423 is a genuine Titan Tool TR1 line-striping tip documented in official Titan PowrLiner literature. The TR1 family provides contractors with multiple fan-width and orifice combinations for matching stripe dimensions, coating delivery and film build to professional marking requirements. |
| Commercial Benefits | The 423 combines the common 4-inch professional marking width with substantial material delivery from a .023-inch opening. It gives contractors a manufacturer-specified heavy-film option for compatible traffic paints while retaining the convenience of Titan's reversible line-striping tip design. |
Contractor Selection Insight
Choose Titan 697-423 when you need a 4-inch nominal stripe with heavy coating deposition and your traffic paint is approved for a .023-inch opening. Do not substitute 697-823 based only on the shared .023-inch orifice: the 423 concentrates the material into a 4-inch pattern, while the 823 spreads it across an 8-inch nominal pattern and carries a different film classification.
FAQ Section
Key answers for contractors selecting Titan 697-423 TR1.
