Titan 138038 Screen

Titan 138038 Screen

Sourced From:
Titan Tools Inc.





Titan part 138038 is a screen used to filter debris and contaminants from the fluid system on compatible Helix FR and VR sprayers. When the original screen becomes clogged or damaged, it can restrict fluid flow, cause pressure loss, and lead to inconsistent spray performance. This screen restores proper filtration and ensures reliable material delivery.

Part Number 138038
Part Description Screen
Brand Helix
Fits Helix FR, Helix VR
Condition New


Retail Price: $393.6
You save: $54.71 (13.90%)
Our Price: $338.89



Fluid System Screen for Helix FR and VR Sprayers

The Titan part 138038 Screen is a filtration component designed to remove debris and contaminants from the fluid system of Helix FR and VR sprayers. This screen traps particles that could otherwise damage pump packings, valves, and spray tips, ensuring reliable operation and consistent finish quality.

A clogged or damaged screen can restrict fluid flow, cause pressure fluctuations, and lead to frequent tip clogs. Replacing with this genuine component ensures proper filtration, protects downstream components, and maintains optimal sprayer performance.

Filtration Note: Regular inspection and cleaning of the screen is essential for preventing performance issues. Replace the screen if it shows signs of damage or if cleaning no longer restores proper flow.

What it does and when to replace it

What the screen does
Debris filtration Traps contaminants that could damage system components
Component protection Prevents particles from entering pump and spray tip
Flow maintenance Ensures consistent material delivery
Finish quality Helps maintain smooth, defect-free spray patterns
When replacement is recommended
Visible clogging Screen visibly blocked with debris
Physical damage Tears, holes, or deformation of screen mesh
Flow restriction Reduced material flow despite cleaning
Routine maintenance Replace during scheduled service intervals

Compatibility

Titan part 138038 is designed for use in Helix FR and Helix VR sprayer models. This screen is a direct replacement for the original component.

Model Series Component
Helix FR (all models) Screen
Helix VR (all models) Screen

Related parts commonly serviced together

When replacing the screen, these related fluid system components are often inspected or replaced to ensure complete system reliability.

Screen housing

Inspect for cracks or damage that could cause leaks.

Seals and O-rings

Replace any seals disturbed during screen service.

Suction strainer

Primary filtration at material intake should also be checked.

Frequently Asked Questions

The 138038 screen is manufactured to the original equipment specifications for Helix FR and VR sprayers, providing the appropriate mesh size for effective filtration of typical coating materials. The screen is designed to capture particles that could damage pump components or clog spray tips while maintaining adequate flow rates for production spraying.

Screen inspection frequency depends on usage and material types. For daily use, inspect the screen weekly for debris buildup or damage. For occasional use, inspect at each material change or at least monthly. Replace the screen if you notice reduced flow, visible damage, or if cleaning no longer restores proper performance. Regular inspection prevents unexpected downtime and protects downstream components.

Cleaning with appropriate solvent and a soft brush is recommended for routine maintenance. However, screens have a finite service life—repeated cleaning can degrade the mesh, and abrasive materials can erode the screening surface. If the screen shows visible damage, cannot be thoroughly cleaned, or if you're experiencing persistent contamination issues, replacement is the best course of action.

Yes, the 138038 screen is designed to fit both Helix FR (Flush Recovery) and Helix VR (Vacuum Recovery) models. While these series have different recovery systems, they share common fluid filtration components, including this screen. Always verify compatibility with your specific model and the location where the screen will be installed.
