Titan OEM part 0532467A is a complete Fluid Section Assembly for the Impact 410 airless sprayer. This assembly is the core pumping component that houses the piston, seals, and valves responsible for generating high pressure. Replacing this complete unit is the most effective way to restore the pump to its original performance and pressure specifications.
| Part Number | 0532467A |
|---|---|
| Part Description | Fluid Section Assembly |
| Brand | Titan |
| Fits | Impact 410 (Low Rider, Stand, Skid models) |
| Condition | New, Genuine OEM |
The Titan 0532467A Fluid Section Assembly is the genuine OEM core pumping unit for the Titan Impact 410 airless sprayer. This complete, pre-assembled kit contains the piston, valves, seals, and pump body, making it the definitive solution for a comprehensive pump overhaul. It restores the high-pressure fluid system to factory specifications, ensuring reliable operation and consistent material delivery.
Replacing individual seals or valves can be a temporary fix when the core components are worn. This complete fluid section assembly solves persistent pressure loss, internal wear, and seal failure by renewing all critical internal parts simultaneously. It is the recommended repair for high-hour machines or pumps that have suffered from contamination or dry running.
| Pressure Generation | Houses the reciprocating piston and seals that create the high pressure (up to 3300 PSI) needed to atomize paint. |
|---|---|
| Fluid Control | Contains the inlet and outlet valves that regulate the one-way flow of material through the pump. |
| System Integrity | Forms the sealed, high-pressure chamber that contains the fluid path from the suction tube to the pump outlet. |
| Severe Pressure Loss | Inability to reach or maintain pressure, not solved by replacing packings alone. |
|---|---|
| Internal Scoring/Wear | Visible wear or grooves on the piston or inside the pump cylinder wall. |
| Recurrent Seal Failure | Packing kits fail repeatedly in a short period, indicating worn mating surfaces. |
| Major Contamination | Abrasive material (e.g., sanding dust) has entered and damaged the fluid system. |
Titan part 0532467A is a direct replacement for the following specific Titan Impact 410 configurations. It is crucial to match the part number to your exact model variant.
| Titan Model | Compatible Configuration |
|---|---|
| Titan Impact 410 | Low Rider Model |
| Titan Impact 410 | Stand Model |
| Titan Impact 410 | Skid Model |
This part is not compatible with the Titan Impact 410 High Rider model.
When performing a major pump overhaul with a new fluid section, these related items are often inspected, cleaned, or replaced to ensure a complete and reliable repair.
Essential. New packings and the piston must be lubricated with genuine Titan pump grease during installation.
Inspect and clean or replace the suction tube and inlet filter to protect the new assembly from debris.
Ensure downstream filters are clean to prevent clogs and back-pressure that could affect the new pump.
