Titan part 0509180 is a complete Suction Set Assembly designed for the fluid intake system of compatible Titan airless sprayers. This assembly includes all necessary components for drawing material from the container to the pump, ensuring proper priming and consistent fluid flow. A properly functioning suction set is critical for reliable sprayer operation and preventing air ingestion that can cause performance issues.
| Part Number | 0509180 |
|---|---|
| Part Description | Suction Set Assembly |
| Brand | Titan |
| Fits | Advantage GPX 130, Advantage GPX 165 models |
| Condition | New |
The Titan 0509180 Suction Set Assembly is a complete fluid intake system component designed for Titan Advantage GPX series airless sprayers. This assembly typically includes the suction tube, fittings, washers, and any specialized components needed to create a reliable connection between the material container and the sprayer pump. The suction set is responsible for efficiently drawing coating material from the container while preventing air leaks that can cause priming difficulties and inconsistent spraying.
A worn, damaged, or incomplete suction set can lead to numerous operational problems including difficulty priming, air ingestion (cavitation), reduced fluid flow, and intermittent spraying. These issues often manifest as spitting at the spray gun, loss of pressure, or inability to maintain a consistent spray pattern. Replacing the entire suction set assembly ensures all components work together properly and eliminates potential weak points in the fluid intake system.
When installing a new suction set assembly, ensure all connections are properly tightened and the suction tube reaches the bottom of the material container. Check for any kinks or restrictions in the tube path. After installation, prime the system according to the sprayer manufacturer's instructions to verify proper fluid flow and check for any leaks at the connections.
| Suction tube/hose | Flexible tubing that draws material from container to pump. |
|---|---|
| Strainer/filter | Prevents large debris from entering the pump assembly. |
| Fittings/adapters | Connectors that secure the assembly to pump and container. |
| Gaskets/seals | Ensure airtight connections throughout the intake path. |
| Fluid transfer | Efficiently moves material from container to pump intake. |
|---|---|
| Air exclusion | Maintains airtight system to prevent air ingestion. |
| Debris protection | Filters out particles that could damage pump components. |
| Priming assistance | Creates proper suction for initial pump priming. |
Titan part 0509180 is specifically designed for Titan Advantage GPX series airless sprayers. The "GPX" designation typically refers to Graco Professional Xtreme series-compatible models, and the 130 and 165 numbers indicate specific pump sizes or configurations. This suction set assembly is engineered to match the original equipment specifications for these professional-grade sprayers.
| Compatible Models | Series | Component Type |
|---|---|---|
| Advantage GPX 130 | Advantage GPX Series | Suction Set Assembly |
| Advantage GPX 165 | Advantage GPX Series | Suction Set Assembly |
The suction set assembly should be replaced when individual components show wear or when systemic intake problems occur. Consider replacement under these conditions:
Consistent trouble getting the sprayer to prime or maintain prime.
Cracks in tubing, damaged fittings, or deteriorated seals/gaskets.
Sprayer draws air into system causing sputtering or inconsistent flow.
